LCSR Programming Model
http://www.motorola.com/computer/literature 2-77
2
Local Bus Interrupter Status Register (bits 24-31)
This register is the local bus interrupter status register. When an interrupt
status bit is high, a local bus interrupt is being generated. When an interrupt
status bit is low, a local interrupt is not being generated. The interrupt
status bits are:
TIC1 Tick timer 1 interrupt.
TIC2 Tick timer 2 interrupt
VI1E VMEbus IRQ1 edge-sensitive interrupt.
PE Not used on MVME1x7P.
MWP VMEbus master write post error interrupt.
SYSF VMEbus SYSFAIL interrupt.
AB Not used on MVME1x7P.
ACF VMEbus ACFAIL interrupt.
ADR/SIZ $FFF40068 (8 bits of 32)
BIT 31 30 29 28 27 26 25 24
NAME ACF AB SYSF MWP PE VI1E TIC2 TIC1
OPER RRRRRRRR
RESET 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL
