LCSR Programming Model
http://www.motorola.com/computer/literature 2-81
2
Local Bus Interrupter Enable Register (bits 24-31)
This register is the local bus interrupter enable register. When an enable bit
is high, the corresponding interrupt is enabled. When an enable bit is low,
the corresponding interrupt is disabled. The enable bit does not clear
edge-sensitive interrupts or prevent the flip-flop from being set. If
necessary, edge-sensitive interrupters should be cleared to remove any old
interrupts and then re-enabled.
ETIC1 Enable tick timer 1 interrupt.
ETIC2 Enable tick timer 2 interrupt.
EVI1E Enable VMEbus IRQ1 edge-sensitive interrupt.
EPE Not used on MVME1x7P.
EMWP Enable VMEbus master write post error interrupt.
ESYSF Enable VMEbus SYSFAIL interrupt.
EAB Not used on MVME1x7P.
EACF Enable VMEbus ACFAIL interrupt.
ADR/SIZ $FFF4006C (8 bits of 32)
BIT 31 30 29 28 27 26 25 24
NAME EACF EAB ESYSF EMWP EPE EVI1E ETIC2 ETIC1
OPER R/W R/W R/W R/W R/W R/W R/W R/W
RESET 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL
