2-104 Computer Group Literature Center Web Site
VMEchip2
2
VMEchip2 ID Register
This register is the VMEchip2 ID register. The ID for the VMEchip2 is 10.
VMEchip2 LM/SIG Register
This register is the VMEchip2 location monitor register and the interrupt
register.
SIG0 The SIG0 bit is set when a VMEbus master writes a 1 to
it. When the SIG0 bit is set, an interrupt is sent to the local
bus interrupter. The SIG0 bit is cleared when the local
processor writes a 1 to the SIG0 bit in this register or the
CSIG0 bit in the local interrupt clear register.
SIG1 The SIG1 bit is set when a VMEbus master writes a 1 to
it. When the SIG1 bit is set, an interrupt is sent to the local
bus interrupter. The SIG1 bit is cleared when the local
processor writes a 1 to the SIG1 bit in this register or the
CSIG1 bit in the local interrupt clear register.
SIG2 The SIG2 bit is set when a VMEbus master writes a 1 to
it. When the SIG2 bit is set, an interrupt is sent to the local
bus interrupter. The SIG2 bit is cleared when the local
processor writes a 1 to the SIG2 bit in this register or the
CSIG2 bit in the local interrupt clear register.
ADR/SIZ Local Bus: $FFF40100/VMEbus: $XXY0 (8 bits)
BIT 7. . .0
NAME VMEchip2 ID Register
OPER R
RESET 10 PS
ADR/SIZ Local Bus: $FFF40104/VMEbus: $XXY2 (8 bits)
BIT 15 14 13 12 11 10 9 8
NAME LM3 LM2 LM1 LM0 SIG3 SIG2 SIG1 SIG0
OPER RRRRS/RS/RS/RS/R
RESET 1 PS 1 PS 1 PS 1 PS 0 PS 0 PS 0 PS 0 PS
