3-26 Computer Group Literature Center Web Site
PCCchip2
3
INT Interrupt Status. When this bit is high a Tick Timer 2
interrupt is being generated at the level programmed in
IL2-IL0 (if nonzero). This bit is edge-sensitive and can be
cleared by writing a logic 1 into the ICLR control bit.
Tick Timer 1 Interrupt Control Register
IL2-IL0 Interrupt Request Level. These three bits select the
interrupt level for Tick Timer 1. Level 0 does not generate
an interrupt.
ICLR Writing a logic 1 into this bit clears the INT status bit.
This bit is always read as zero.
IEN Interrupt Enable. When this bit is high, the interrupt is
enabled. The interrupt is disabled when this bit is low.
INT Interrupt Status. When this bit is high a Tick Timer 1
interrupt is being generated at the level programmed in
IL2-IL0 (if nonzero). This bit is edge-sensitive and can be
cleared by writing a logic 1 into the ICLR control bit.
ADR/SIZ $FFF4201B (8 bits)
BIT 76543210
NAME INT IEN ICLR IL2 IL1 IL0
OPER R R R R/W C R/W R/W R/W
RESET 0 0 0 PL 0 PL 0 PL 0 PL 0 PL 0 PL
