3-36 Computer Group Literature Center Web Site
PCCchip2
3
LANC Bus Error Interrupt Control Register
IL2-IL0 Interrupt Request Level. These three bits select the
interrupt level. Level 0 does not generate an interrupt.
ICLR Writing a logic 1 into this bit clears the INT status bit.
This bit is always read as zero.
IEN Interrupt Enable. When this bit is high, the interrupt is
enabled. The interrupt is disabled when this bit is low.
IRQ Interrupt Status. When this bit is high, a LANC Bus Error
interrupt is being generated at the level programmed in
IL2-IL0 (if nonzero).
SC1-SC0 Snoop Control. These control bits determine the value that
the PCCchip2 drives onto the local MC68040 bus SC1
and SC0 pins, when the 82596CA (LANC) performs
DMA accesses.
During LANC DMA, if bit SC0 is 0 Local Bus pin SC0 is
low, and when bit SC0 is 1, pin SC0 is high. The same
relationship holds true for bit and pin SC1. See the
M68040 user’s manual for details on how it uses the
Snoop Control signals.
Note On the MVME177P, which uses only SC1, the SC0 bit must be 0.
ADR/SIZ $FFF4202B (8 bits)
BIT 76543210
NAME SC1 SC0 INT IEN ICLR IL2 IL1 IL0
OPER R/W R/W R R/W C R/W R/W R/W
RESET 0 PL 0 PL 0 PL 0 PL 0 PL 0 PL 0 PL 0 PL
