Programming Model
http://www.motorola.com/computer/literature 4-13
4
Chip ID Register
The Chip ID register is hard-wired to a hexadecimal value of $81. The
Petra MCECC sector can be given a software reset by writing a value of
$0F to this register. This write is terminated properly with TA∗ and sets
most internal registers to their default (power-up) state. Although writes of
any value other than $0F to this register are ignored, the MCECC sector
always terminates the cycles properly with TA∗.
Chip Revision Register
The Chip Revision register is hard-wired to reflect the revision level of the
Petra/MCECC ASIC. The current value of the register is $01. Although
writes to this register are ignored, the MCECC sector pair always
terminates the cycles properly with TA∗.
ADR/SIZ 1st $FFF43000/2nd $FFF43100 (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME CID7 CID6 CID5 CID4 CID3 CID2 CID1 CID0
OPER RRRRRRRR
RESET XXXXXXXX
ADR/SIZ 1st $FFF43004/2nd $FFF43104 (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME REV7 REV6 REV5 REV4 REV3 REV2 REV1 REV0
OPER RRRRRRRR
RESET XXXXXXXX
