Programming Model
http://www.motorola.com/computer/literature 4-17
4
Note This register is configured only during power-up-reset and is
unchanged by software or local reset.
Data Control Register
RWCKB READ/WRITE CHECKBITS, when set, enables the data
from the seven checkbits in the Petra MCECC sector (bits
30-24) to be written and read on the local MC680x0 data
bus. This bit should be cleared for normal system
operation.
Note that if test software forces a single-bit error to a
location (line) using this function, the scrubber may
correct the location before the test software gets a chance
to check for the single-bit error at that location. This can
be avoided by disabling scrubbing and making sure that
all previous scrubs have completed before performing the
test. Also note that writing bad checkbits can set the
ERRLOG bit in the Error Logger register.
ADR/SIZ 1st $FFF4301C/2nd $FFF4311C (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME BCK7 BCK6 BCK5 BCK4 BCK3 BCK2 BCK1 BCK0
OPER R/W R/W R/W R/W R/W R/W R/W R/W
RESET 0 P0 P0 P1 P1 P0 P0 P1P
ADR/SIZ 1st $FFF43020/2nd $FFF43120 (16-bits)
BIT 31 30 29 28 27 26 25 24
NAME 00DERCZFILLRWCKB000
OPER RRR/WR/WR/WRRR
RESET X X 1 PLS 0 PLS 0 PLS X X X
