4-26 Computer Group Literature Center Web Site
MCECC Functions
4
Scrub Address Counter (Bits 23-16)
This register reflects the current value in the Scrub Address counter bits
23-16.
Scrub Address Counter (Bits 15-8)
This register reflects the current value in the Scrub Address counter bits
15-8.
Scrub Address Counter (Bits 7-4)
This register reflects the current value in the Scrub Address counter bits 7-
4.
ADR/SIZ 1st $FFF43050/2nd $FFF43150 (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME SAC23 SAC22 SAC21 SAC20 SAC19 SAC18 SAC17 SAC16
OPER R/W R/W R/W R/W R/W R/W R/W R/W
RESET 0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS
ADR/SIZ 1st $FFF43054/2nd $FFF43154 (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME SAC15 SAC14 SAC13 SAC12 SAC11 SAC10 SAC9 SAC8
OPER R/W R/W R/W R/W R/W R/W R/W R/W
RESET 0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS
ADR/SIZ 1st $FFF43058/2nd $FFF43158 (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME SAC7SAC6SAC5SAC40000
OPER R/WR/WR/WR/WRRRR
RESET 0 PLS0 PLS0 PLS0 PLSXXXX
