Programming Model
http://www.motorola.com/computer/literature 4-29
4
Error Address (Bits 15-8)
This register reflects the value that was on bits 15-8 of the local MC680x0
address bus at the last logging of an error.
Error Address (Bits 7-4)
This register reflects the value that was on bits 7-4 of the local MC680x0
bus at the last logging of an error.
ADR/SIZ 1st $FFF43068/2nd $FFF43168 (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME EA15 EA14 EA13 EA12 EA11 EA10 EA9 EA8
OPER RRRRRRRR
RESET 0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS0 PLS
ADR/SIZ 1st $FFF4306C/2nd $FFF4316C (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME EA7EA6EA5EA40000
OPER RRRRRRRR
RESET 0 PLS0 PLS0 PLS0 PLSXXXX
