4-32 Computer Group Literature Center Web Site
MCECC Functions
4
being set. The state of FSTRD after a reset (power-up,
soft, or local) is determined by board-level configuration
resistors.
RWB6 Read/Write Bit 6 is a general-purpose read/write bit.
RWB7 Read/Write Bit 7 is a general-purpose read/write bit.
Defaults Register 2
It is not recommended that non-test software write to this register.
RESST2-RESST0
These general-purpose read/write bits are initialized by a
power-up, soft, or local reset to match the RESST2-
RESST0 bits from the reset serial bit stream.
ADR/SIZ 1st $FFF43078/2nd $FFF43178 (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME 00000RESST2 RESST1 RESST0
OPER R/W R/W R/W R/W R/W R/W R/W R/W
RESET 0 PLS 0 PLS 0 PLS V PLS V PLS V PLS V PLS V PLS
