Functional Description
http://www.motorola.com/computer/literature 1-19
1
Notes
1.
RESET switch control.
2. Watchdog timer control.
3. Access and watchdog timer parameters.
4. MPU TEA (bus error) status
5. Bit numbering for the VMEchip2 and Petra ASICs has a one-to-one
correspondence.
6.
ABORT switch interrupt control. Implemented also in the
VMEchip2, but with a different bit organization (refer to the
VMEchip2 description in Chapter 2). In the MVME1X7P, the
ABORT switch is wired to the Petra chip, not the VMEchip2.
7. The SRAM and EPROM decoder in the VMEchip2 (version 2) must
be disabled by software before any accesses are made to these
address spaces.
Table 1-2. Functions Duplicated in VMEchip2 and Petra ASICs
VMEchip2 Petra Chip
Notes
Address Bit # Address Bit #
$FFF40060 28-24 $FFF42044 28-24 1,5
$FFF40060 22-19,
17,16
$FFF42044 22-19,
17,16
2,5
$FFF4004C 13-8 $FFF42044 13-8 3,5
$FFF40048 7 $FFF42048 8 4
$FFF40048 9 $FFF42048 9 4,5
$FFF40048 10 $FFF42048 10 4,5
$FFF40048 11 $FFF42048 11 4,5
$FFF40064 31-0 $FFF4204C 3-0 8
$FFF42040 6- 0 6
$FF800000-$FFBFFFFF 31-0 $FF800000-$FFBFFFFF 31-0 7
$FFE00000-$FFEFFFFF 31-0 Programmable 31-0 7
