Programming Issues
1
8. 32-bit prescaler. The prescaler can also be accessed at $FFF40064
when the optional VMEbus is not enabled.
Memory Maps
There are two points of view for memory maps:
1. The mapping of all resources as viewed by local bus masters (local
bus memory map)
2. The mapping of onboard resources as viewed by VMEbus masters
(VMEbus memory map)
The memory maps and I/O maps described in the following tables are
correct for all local bus masters. Some address translation capability exists
in the VMEchip2. This capability makes it possible to have multiple
MVME1X7P modules on the same VMEbus with different virtual local
bus maps as viewed by different VMEbus masters.
Local Bus Memory Map
The local bus memory map is split into different address spaces by the
transfer type (TT) signals. The local resources respond to the normal
access and interrupt acknowledge codes.
Normal Address Range
The following tables show the memory maps of devices that respond to the
normal address range. The normal address range is defined by the Transfer
Type (TT) signals on the local bus. On the MVME1X7P, Transfer Types
0, 1, and 2 define the normal address range.
Table 1-3 is the entire map from $00000000 to $FFFFFFFF. Many areas
of the map are user-programmable, and suggested uses are shown in the
table. The cache inhibit function is programmable in the MC680x0 MMU.
