Memory Maps
http://www.motorola.com/computer/literature 1-21
1
The onboard I/O space must be marked cache-inhibit and serialized in its
page table. Table 1-4 on page 1-22 further defines the map for the local I/O
devices on the MVME1X7P.
Notes
1. ROM on MVME167P, ROM/Flash on MVME177P. Flash/EPROM
devices appear at $FF800000 - $FFBFFFFF, and also appear at
$00000000 - $003FFFFF if the ROM0 bit in the VMEchip2
EPROM control register is high (ROM0 = 1).
The ROM0 bit is located at address $FFF40030 bit 20. ROM0 is set
to 1 after each reset. The ROM0 bit must be cleared before other
resources (DRAM or SRAM) can be mapped in this range
Table 1-3. Local Bus Memory Map
Address
Range
Devices Accessed Port Size Size
Software
Cache
Inhibit
Notes
$00000000 -
DRAMSIZE
User Programmable
(Onboard SDRAM)
D32
DRAMSIZE
N1, 2
DRAMSIZE -
$FF7FFFFF
User Programmable
(VMEbus)
D32/D16 3GB ? 3, 4
$FF800000 -
$FFBFFFFF
ROM (167P) D32 4MB N 1
EPROM/Flash (177P) D32
2MB
EPROM,
4MB Flash
N1,6
$FFC00000 -
$FFDFFFFF
Reserved -- 2MB -- 5
$FFE00000 -
$FFE1FFFF
SRAM D32 128KB N --
$FFE20000 -
$FFEFFFFF
SRAM (repeated) D32 896KB N --
$FFF00000 -
$FFFEFFFF
Local I/O Devices
(Refer to next table)
D32-D8 1MB Y 3
$FFFF0000 -
$FFFFFFFF
User Programmable
(VMEbus A16)
D32/D16 64KB ? 2, 4
