Memory Maps
http://www.motorola.com/computer/literature 1-41
1
Note Accesses may be 8-bit or 32-bit, but not 16-bit.
BBRAM/TOD Clock Memory Map
The M48T58 BBRAM (also called Non-Volatile RAM or NVRAM) is divided into
six areas as shown in Table 1-12. The first five areas are defined by software, while
the sixth area, the time-of-day (TOD) clock, is defined by the chip hardware. The
first area is reserved for user data. The second area is used by Motorola networking
software. The third area may be used by an operating system. The fourth area is
Table 1-11. 53C710 SCSI Memory Map
Base Address is $FFF47000
Big Endian
Mode
53C710 Register Address Map SCRIPTs Mode and
Little Endian Mode
00 SIEN SDID SCNTL1 SCNTL0 00
04 SOCL SODL SXFER SCID 04
08 SBCL SBDL SIDL SFBR 08
0C SSTAT2 SSTAT1 SSTAT0 DSTAT 0C
10 DSA 10
14 CTEST3 CTEST2 CTEST1 CTEST0 14
18 CTEST7 CTEST6 CTEST5 CTEST4 18
1C TEMP 1C
20 LCRC CTEST8 ISTAT DFIFO 20
24 DCMD DBC 24
28 DNAD 28
2C DSP 2C
30 DSPS 30
34 SCRATCH 34
38 DCNTL DWT DIEN DMODE 38
3C ADDER 3C
