User’s manual EP562 Expansion 5.
Congratulations on purchasing your new AT&T product. Please read this user’s manual for the information necessary to install your new AT&T product. For complete instructions, please refer to the manual provided with your EP5632/EP5632-2 telephone, which can be downloaded from our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada dial 1 (866) 288-4268. Model #: EP562 Product name: 5.
Before you begin you must install and charge the battery, see page 2 for Battery installation instructions. Please read and follow these instructions carefully: • Use only the supplied rechargeable battery or replacement battery. • Observe the proper polarity orientation between the battery and handset during the battery installation. • Do not dispose the battery in a fire. Check with local codes for special disposal instructions. • Do not open or mutilate the battery.
Getting started Parts checklist Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service. Cordless telephone handset 80-5808-00-00 BATTERY PACK Your new AT&T EP562 expansion handset includes: Handset battery Handset battery compartment cover Belt clip User’s manual EP562 Expansion 5.
Getting started Battery installation 1. Press the tab and slide the battery compartment cover downwards (if necessary). 80-5808-00-00 BATTERY PACK Install the battery as shown below. After installing the battery, you need to register the handset with the telephone base (page 4). Once registered, you can make and receive short calls. For optimal performance, charge the handset battery for at least 16 hours before use (page 3). 2. Insert the supplied battery as indicated.
Getting started Battery charging For optimal performance, charge the handset battery for at least 16 hours before use. When fully charged, the handset battery provides approximately five hours of talk time and three days of standby time. Electrical outlet not controlled by a wall switch Power adapter Charger 1. Plug the small end of the power adapter into the jack on the underside of the charger, then route the cord through the shot as shown. 2.
Getting started Adding your new handset Before using a newly purchased handset (EP562), it must be registered with the telephone base. If you already have 12 handsets registered to the same telephone base and you wish to replace your newly purchased handset with another, see page 5. Register Handset 12:00AM Place in Charger 12:00AM Register handset: Press MENU in the base. Find 'Register Handset' in the main menu. Press SELECT. 12:00AM Registration in progress...
Getting started Replacing a handset NOTE: If you replace a registered handset, the new handset will be assigned the next available registration number, rather than the handset number of the handset you will replace. When you are replacing rather than adding a handset, for your handsets to be numbered sequentially, you need to delete all the handset registrations on the telephone base. Settings Clear Voice Mail Default Settings Delete Handsets 1.
Getting started Quick reference guide Handset Status light VOLUME Flashes rapidly during an incoming call, and when there is a new voice mail message or new message in the answering system. Press to adjust handset listening volume while on a call. Softkeys (2) During a HOME or CELLULAR line call, press to end the call. Press to select a menu item displayed just above the key. OFF/CANCEL 12:00AM HANDSET 1 HOME/FLASH Press to make or answer a HOME call.
Getting started Handset main menu To enter the main menu: 1. Press MENU/SELECT when the handset is in idle mode. 2. Press the UP and DOWN Navkeys to select a handset feature menu, then press MENU/SELECT to enter that menu. To return to the idle mode, press and hold OFF/CANCEL. Settings allows you to change your handset settings. Directory allows you to store and search for names and numbers. Directory Settings Settings Call Log allows you to review your most recent incoming calls.
Getting started Belt clip & optional headset Install belt clip as shown below, if desired. To remove the belt clip: Gently lift either of the belt clip retaining tabs, shown in the figure, outwards to remove the belt clip from the handset. To attach the belt clip: Snap the belt clip into the retaining tabs on both sides of the handset as shown in the figure. For handsfree headset conversations, use any industry standard 2.5 mm headset (purchased separately). For best results, use an AT&T 2.5 mm headset.
Appendix Troubleshooting If you have difficulty with your telephone, please try the suggestions below. For complete instructions, please refer to the user’s manual provided with your EP5632/EP5632-2 telephone system, which can be downloaded from our website at www.telephones.att.com, or call 1 (800) 222–3111. In Canada, dial 1 (866) 288-4268. My telephone does not work at all. • Make sure the handset battery is installed and charged correctly.
Appendix The battery does not charge in the handset • Make sure the handset is placed in the charger correctly. The CHARGE light on the charger should be on. -OR- • If the cordless handset is in the charger or in the telephone base but the CHARGE light is not on, refer to The CHARGE light is off in the section below. Low Battery is constantly displayed on the handset.
Appendix The telephone does not ring when there is an incoming call. • Make sure the ringer is on. • Make sure the telephone line cord and power adapter are plugged in properly. • The cordless handset may be too far from the telephone base. Move it closer to the telephone base. • There may be too many extension phones on the telephone line to allow all of them to ring simultaneously. Try unplugging some of them.
Appendix There is noise or interference during a telephone conversation. -ORMy calls fade out or cut in and out when I am using the cordless handset. • The handset may be out of range. Move it closer to the telephone base. • Appliances or other cordless telephones plugged into the same circuit as the telephone base can cause interference. Try moving the appliances or telephone base to another outlet. • Other electronic products can cause interference to your cordless telephone.
Appendix My caller ID features are not working properly. • Caller ID is a subscription service. You must subscribe to this service from your local telephone company for this feature to work on your telephone. • The caller may not be calling from an area which supports caller ID. • Both you and the caller’s telephone companies must use equipment which are compatible with caller ID service.
Appendix Technical specifications Operating temperature 0°C to 50°C (32°F to 122°F) Power input voltage 120V AC 60Hz Handset charger output voltage 9V DC 150mA Handset battery 3.6V 600mAh (NiMH) Cordless system operating frequency 5.725 GHz to 5.850 GHz Telephone operating range This cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC).
Appendix Important safety instructions This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. Safety information • Read and understand all instructions in the user’s manual. Observe all markings on the product. • Avoid using a telephone during a thunderstorm. There may be a slight chance of electric shock from lightning.
Appendix Important safety instructions • If this product has user-replaceable batteries, replace batteries only as described in your user’s manual. Do not burn or puncture batteries — they contain caustic chemicals. • If this product has a three-prong (grounding) plug or a polarized plug with one wide prong, it may not fit in nonpolarized outlets. Do not defeat the purpose of these plugs. If they do not fit in your outlet, the outlet should be replaced by an electrician.
Appendix Important safety instructions • Potential TV interference: Some cordless telephones operate at frequencies that may cause interference to TVs and VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR will often reduce or eliminate the interference.
Appendix Important safety instructions Precautions for users of implanted cardiac pacemakers Cardiac pacemakers (applies only to 900 MHz digital cordless telephones): Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S.
Appendix FCC Part 68 and ACTA This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US: AAAEQ##TXXXX. This identifier must be provided to your local telephone company upon request.
Appendix FCC Part 68 and ACTA If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is required to notify you before interrupting service. If advance notice is not practical, you will be notified as soon as possible.
Appendix FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Appendix Limited warranty The AT&T brand is used under license - any repair, replacement or warranty service, and all questions about this product should be directed to: In the United States of America, visit ������ www.telephones.att.com or call ����� 1 (800) 222-3111. In Canada dial 1 (866) 288-4268. 1.
Appendix Limited warranty 3. How long is the limited warranty period? The limited warranty period for the PRODUCT extends for ONE (1) YEAR from the date of purchase.
Appendix Limited warranty • PRODUCT returned without valid proof of purchase (see item 6 below); or • Charges for installation or setup, adjustment of customer controls, and installation or repair of systems outside the unit. 5. How do you get warranty service? To obtain warranty service in the United States of America, visit www.telephones.att.com or call 1 (800) 222-3111. In Canada, call 1 (866) 288-4268.
Appendix Limited warranty 6. What must you return with the PRODUCT to get warranty service? You must: a. Return the entire original package and contents including the PRODUCT to the service location along with a description of the malfunction or difficulty; and b. Include “valid proof of purchase” (sales receipt) identifying the PRODUCT purchased (PRODUCT model) and the date of purchase or receipt; and c. Provide your name, complete and correct mailing address, and telephone number. 7.
Appendix Limited warranty Limitations: Implied warranties, including those of fitness for a particular purpose and merchantability (an unwritten warranty that the PRODUCT is fit for ordinary use) are limited to one year from date of purchase. Some states/provinces do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
