LED
LED indicator descriptions
LAN ACT OFF when no activity; BLINKING when frames are being transmitted or
received on the line
T1/E1 Sync ON when the port is synchronized (no alarm); OFF when Loss of signal
(LOS); one LED for each T1/E1
1.2.6 Features
The Canopy T1/E1 Multiplexer
◦ installs easily.
◦ multiplexes up to 4 T1 or 3 E1 circuits onto a Canopy Backhaul point-to-point
link.
◦ enables T1/E1 extension over Ethernet networks.
◦ supports
− synchronous TDM-based services over wireless Ethernet networks.
− CAS signaling transparent to all other signaling protocols on T1/E1.
− 10Base-T/100Base-TX uplink to the network.
− management interfaces.
− simplified troubleshooting through T1/E1 line loopback test.
1.2.7 Specifications
Physical Specifications
Table 4 lists the physical specifications for the Canopy T1/E1 Multiplexer.
Table 4: Canopy T1/E1 Multiplexer physical specifications
Specification Description
Option 1: 100/240 v, 47−63 Hz, 0.4 A (+3.3 v DC) DC Power
Option 2: −48 v DC
LAN Connection 2-100Base-TX, RJ-45 cable provided
T1/E1 Connections 4
Control Port RS-232, DB9 (female)
Indicators power, ready, Canopy BH Ethernet link; Canopy BH Ethernet
activity; LAN Ethernet link; LAN Ethernet activity; T1/E1
synchronization (one per port)
Temperature 0° C to 40° C
Humidity 95% non-condensing
Dimensions 1.52” (3.86 cm) high x 5.57" (14.15 cm) wide and 7.50" (19.05 cm)
deep
Weight 1.5 pounds (680 grams)
