Canopy T1/E1MultiplexerSeptember2004
T1/E1MultiplexerFPGAVersion3.4
Page39 of 73
2.4.5 ConfigurePorts
Procedure 10: Configuring the Ethernet ports using the CLI
Perform this procedure to configure the Ethernet ports using the CLI manager.
NOTE: Both Ethernet ports operate at 100 Mbps Full Duplex. They will not operate at
10 Mbps or at half duplex.
Action Steps
Log in Press Enter.
At the username prompt, enter admin.
At the password prompt, enter password.
Set BH-side Ethernet auto-
negotiation
Enter set canopy port auto negotiation [on/off]
where
on enables auto negotiation at 100 Mbps Full Duplex (as default).
off forces the port to 100 Mbps Full Duplex without auto negotiation.
RESULT: The system responds
Canopy port auto-negotiation is: on
Set LAN-side Ethernet
auto-negotiation
Enter set lan port auto negotiation [on/off]
where
on enables auto negotiation at 100 Mbps Full Duplex (as default).
off forces the port to 100 Mbps Full Duplex without auto negotiation.
RESULT: The system responds
LAN port auto-negotiation is: on
Log off
Enter lo.
RESULT: The system responds goodbye.
end of procedure
