Action Steps
Set timing mode
NOTE: Timing mode applies to all four E1 lines. Loopback mode loops the T1/E1
Tx clock to the T1/E1 Rx. Recovered mode recovers the T1/E1 clock from the
incoming T1/E1 over Ethernet bit stream (recovers the clock from the far end
T1/E1). The default timing mode is Recovered.
For master clock timing mode, enter
set clock source loopback
RESULT: The system responds
Clock source is loopback
For slave clock timing mode, enter
set clock source recovered
RESULT: The system responds
Clock source is recovered
Log off
Enter lo.
RESULT: The system responds goodbye.
end of procedure
2.5 CONFIGURATIONPROCEDURESUSINGTHEEMS
2.5.1 LoggingintotheSystem
Procedure 14: Logging in using the EMS
If you are using the EMS to access the system, follow the steps below to log in:
1. Select the proper COM Port for your PC.
NOTE: COM1 through COM4 are supported.
2. Enter the User Name.
NOTE: The default username is admin. This value cannot be changed.
3. Enter the Password.
NOTE:The default password is 123. If the password has been changed, enter
the correct password.
4. Select the Login button to continue with the login.
NOTE: If the login is unsuccessful, the system will generate a pop-up error
window. You may return to the Login window to correct the data.
