Canopy T1/E1MultiplexerSeptember2004
T1/E1MultiplexerFPGAVersion3.4
Page53 of 73
3 MANAGINGYOURCANOPYT1/E1MULTIPLEXERS
3.1 REMOTEMANAGEMENTTHROUGHCONTROLPORT
The CONTROL port in the front panel (shown in Figure 6 on Page 14) provides the
capability to remotely manage the Canopy T1/E1 Multiplexer. To do so requires an
Ethernet to
RS-232 converter. An example of such a converter is available at
http://www.precidia.com/products/product1.html.
The configuration for remote management is illustrated in Figure 20.
Canopy T1/E1 Multiplexer
DB9
3.3-v
Wall
Mount
Supply
C
anopy Ethernet
To
Etherne
t
Network
To
E1/T1 Lines
Lightning/
Surge
Protector
Power
over
Ethernet
Canopy
ODU
48-v DC
Supply
Ethernet
Switch
Ethernet
to RS-232
Converter
Figure 20: Remote management overview
Issue3
