3.2 T1/E1ALARMS
Each T1/E1 channel has alarms for line code violation (BPV), receive loss of signal
(LOS), and alarm indication signal (AIS) detection.
Follow these steps to display the alarms using the CLI.
Procedure 23: Displaying the alarms using the CLI
Action Steps
Log in Press Enter.
At the username prompt, enter admin.
At the password prompt, enter password.
View T1/E1 Alarms
Enter get alarms.
The system responds displays alarms for all 4 T1/E1 ports, as in the
following example:
Line1:
Line code violation: No
Receive Loss of Signal: No
Alarm Indication Signal Detect: No
Line2:
Line code violation: No
Receive Loss of Signal: No
Alarm Indication Signal Detect: No
Line3:
Line code violation: No
Receive Loss of Signal: No
Alarm Indication Signal Detect: No
Line4:
Line code violation: No
Receive Loss of Signal: No
Alarm Indication Signal Detect: No
FPGA: 00
Log off
Enter lo.
RESULT: The system responds goodbye.
end of procedure
