Canopy T1/E1MultiplexerSeptember2004
T1/E1MultiplexerFPGAVersion3.4
Page70 of 73
Desired Action Syntax, Response, and Description
View T1/E1 Alarms
Enter get alarms
The system responds displays alarms for all 4 T1/E1 ports, as in the
following example:
Line1:
Line code violation: No
Receive Loss of Signal: No
Alarm Indication Signal Detect: No
Line2:
Line code violation: No
Receive Loss of Signal: No
Alarm Indication Signal Detect: No
Line3:
Line code violation: No
Receive Loss of Signal: No
Alarm Indication Signal Detect: No
Line4:
Line code violation: No
Receive Loss of Signal: No
Alarm Indication Signal Detect: No
FPGA: 00
Read Serial
Number
Reads the serial number of the Canopy T1/E1 Multiplexer.
Get T1/E1
Loopback Mode
Enter get loopback line [1/2/3/4]
where
[1/2/3/4] represents T1/E1 ports 1 through 4
The system responds:
Line [1/2/3/4] loopback is: [on/off]
Displays the loopback status of a T1/E1 line.
Get Firmware
Revision
Enter get firmware revision
The system responds
Firmware revision is: x.y.z
Gets the revision (version number) of the Canopy T1/E1 firmware.
Issue3
