6864110r09o.book Page 3 Friday, December 21, 2001 12:04 PM Motorola Talkabout T5300 and T5400 radios operate on Family Radio Service (FRS) designated frequencies. This license-free, two-way radio service was established specifically for family and group recreational use. Use of this radio outside the country where it was intended to be distributed is subject to government regulations and may be prohibited. Read this manual carefully and make sure you know how to properly operate radio before use.
6864110r09o.book Page 4 Friday, December 21, 2001 12:04 PM Contents Getting Started . . . . . . . . . . . . . . . . . . . . . . 9 Turning On/Off Your Radio . . . . . . . . . . . . 9 Radio Etiquette . . . . . . . . . . . . . . . . . . . . . 9 Diagram of Your Radio . . . . . . . . . . . . . . 10 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Batteries . . . . . . . . . . . . . . . . . . . . . . . . . 11 Installation . . . . . . . . . . . . . . . . . . . . . 11 Meter . . . . . . . . . . . .
SAFETY AND GENERAL INFORMATION IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION READ THIS INFORMATION BEFORE USING YOUR RADIO The information provided in this document supersedes the general safety information contained in user guides published prior to July 2000. For information regarding radio use in a hazardous atmosphere please refer to the Factory Mutual (FM) Approval Manual Supplement or Instruction Card, which is included with radio models that offer this capability.
864110r09o.book Page 2 Friday, December 21, 2001 12:04 PM Safety and General Information • 2 American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.
DO NOT hold the antenna when the radio is “IN USE.” Holding the antenna affects call quality and may cause the radio to operate at a higher power level than needed. Two-way Radio Operation When using your radio as a traditional two-way radio, hold the radio in a vertical position with the microphone one to two inches (2.5 to 5 cm) away from the lips.
Safety and General Information 6864110r09o.book Page 4 Friday, December 21, 2001 12:04 PM 4 ELECTROMAGNETIC INTERFERENCE/COMPATIBILITY Note: Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed or otherwise configured for electromagnetic compatibility. • FACILITIES To avoid electromagnetic interference and/or compatibility conflicts, turn off your radio in any facility where posted notices instruct you to do so.
6864110r09o.book Page 5 Friday, December 21, 2001 12:04 PM not carry the radio in the breast pocket. use the ear opposite the pacemaker to minimize the potential for interference. • turn the radio OFF immediately if you have any reason to suspect that interference is taking place. Hearing Aids Some digital wireless radio may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.
Safety and General Information 6864110r09o.book Page 6 Friday, December 21, 2001 12:04 PM 6 OPERATIONAL WARNINGS • FOR VEHICLES WITH AN AIR BAG Do not place a portable radio in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a portable radio is placed in the air bag deployment area and the air bag inflates, the radio may be propelled with great force and cause serious injury to occupants of the vehicle.
OPERATIONAL CAUTIONS • ANTENNAS Do not use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result. • BATTERIES All batteries can cause property damage and/or bodily injury such as burns if a conductive material such as jewelry, keys, or beaded chains touch exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot.
Safety and General Information 6864110r09o.book Page 8 Friday, December 21, 2001 12:04 PM 8 6. To reduce the risk of electric shock, unplug the charger from the outlet before attempting any maintenance or cleaning. 7. Use of an attachment not recommended or sold by Motorola may result in a risk of fire, electric shock, or personal injury. 8. Make sure that the cord is located so that it will not be stepped on, tripped over, or subjected to damage or stress. 9.
6864110r09o.book Page 9 Friday, December 21, 2001 12:04 PM Getting Started Turning On/Off Your Radio P Display Normal Menu Mode Turn knob on the top of the radio clockwise to use. Turn the knob counterclockwise to turn the radio Off. The radio chirps and the display will show all feature icons that your radio has available for a brief period. T5300 will have the Channel 1-14 on display. Model T5400 display includes the Interference Eliminator Code (0-38) as well as the Channel.
6864110r09o.
6864110r09o.book Page 11 Friday, December 21, 2001 12:04 PM Power Batteries T5300 and T5400 radios operate with 3 AA Alkaline batteries or a NiCd rechargeable battery. A Rechargeable Upgrade Kit model number 53614 is available for T5400. Call 1-800-353-2729 (USA) or 1-800-461-4575 (Canada) for the dealer nearest you, or visit the website; www.motorola.com/talkabout. Installation 1. With back of radio facing you, lift Battery Latch up to release the Battery Cover. 2. Lift cover off. 3.
6864110r09o.book Page 12 Friday, December 21, 2001 12:04 PM Power Battery Life The following chart lists the appropriate battery life during Two-way Use* for AA Alkaline and NiCd batteries. 12 Battery Type Two-way Use* AA Alkaline 27 Hours NiCd (T5400) 12 Hours *Two-way Use is defined as 90% standby time, 5 % talk time, and 5% receive time. Note: Remove batteries before storing your radio for extended periods. Batteries corrode over time and may cause permanent damage to your radio.
6864110r09o.book Page 13 Friday, December 21, 2001 12:04 PM You can charge the battery pack separate from the radio as follows: 1. Plug the wire on the AC Power Supply into the plug on the Desk Stand. 2. Plug the AC Power Supply into a standard wall outlet. 3. Insert the battery pack into the Desk Stand charging pocket using the pocket insert provided. The red light will glow if they have been properly inserted. 4. The radio will be fully charged within 14 hours.
6864110r09o.book Page 14 Friday, December 21, 2001 12:04 PM Talking and Listening Talking and Listening To communicate, all radios in your group must be set to the same Channel (1-14) and Interference Eliminator Code (0-38). T5300 models do not have Interference Eliminator Codes. You must set the Interference Eliminator Code to 0 on a T5400 to communicate with a T5300. • To maximize clarity, hold radio 2 to 3 inches from mouth. • Press and hold M and speak into the microphone.
6864110r09o.book Page 15 Friday, December 21, 2001 12:04 PM Interference Eliminator Code (T5400 Only) The interference eliminator codes help minimize interference by providing you with a choice of code combinations. • To set the code, press \ until the code display begins to blink. • Then press [ or ] to set the code. • Press M to save the code setting. You must set the Interference Eliminator Code to 0 on a T5400 to communicate with a T5300. You can specify a different code for each channel.
6864110r09o.book Page 16 Friday, December 21, 2001 12:04 PM Monitor Button Pressing Q lets you hear the radio’s volume level when you are not receiving so you can adjust the volume. It is also used to check activity on current Channel before transmitting. Time-out Timer The Time-out Timer feature helps extend battery life by preventing accidental transmission. The radio will emit a continuous warning tone after M is pressed for 60 continuous seconds and will stop transmitting.
6864110r09o.book Page 17 Friday, December 21, 2001 12:04 PM Roger Beep/Talk Confirmation Tone When you turn on this feature, your two-way radio transmits a unique tone when you finish transmitting. It’s like saying “Roger” or “Over” and lets others know you’re finished talking. • To enable Roger Beep/Talk Confirmation Tone, press and hold ] as you turn your radio On. Now, when you release M, your set tone lets your friends know you’re finished talking and !will be on the display.
6864110r09o.book Page 18 Friday, December 21, 2001 12:04 PM Accessories There are many accessories (sold separately) available for T5300 and T5400 radios. For more information refer to the brochure we’ve included with your radio, contact place of purchase, or call Motorola at: 1-800-353-2729 USA 1-800-461-4575 Canada 1-800-739-7834 (TTY) Accessories To Use Audio Accessories 1. Make sure radio is Off. Plug accessory connector into jack. 2.
6864110r09o.book Page 19 Friday, December 21, 2001 12:04 PM Problem Solution No Power Reposition, replace or recharge batteries. Erratic Display Reposition, replace or recharge batteries. Message Not Transmitted Make sure button is completely pressed while you transmit. Reposition, replace or recharge batteries. Shared Channel may be in use, try another Channel. Message Not Received Confirm radios have same Channel settings and/or Interference Eliminator Code (helps minimize interference).
6864110r09o.book Page 20 Friday, December 21, 2001 12:04 PM Problem Solution Troubleshooting Hearing Other Shared Channel may be in use, try another. Conversation or Set Eliminator Code to 0 on a T5400 to communicate with a Noise on a T5300. Channel 20 Limited Talk Range Steel/concrete structures, heavy foliage and use in buildings and in vehicles will decrease range, check for clear line of sight to improve transmission.
6864110r09o.book Page 21 Friday, December 21, 2001 12:04 PM Use and Care XXX To clean the radio, use a soft damp cloth. Do not immerse in water. Do not use alcohol or cleaning solutions. Dry with soft cloth. Battery contacts may be wiped with a dry, lint-free cloth. Do not use until completely dry. Turn it off and remove batteries. Use and Care If the radio gets wet...
6864110r09o.book Page 22 Friday, December 21, 2001 12:04 PM Limited Warranty Limited Warranty for Motorola Personal Communications Products and Accessories Purchased in the United States and Canada 22 I.
6864110r09o.book Page 23 Friday, December 21, 2001 12:04 PM Limited Lifetime Warranty Exception. The warranty is a limited lifetime warranty for the lifetime of ownership by the first end-user of the following products, only: (a) decorative covers, including bezel, PhoneWrap™ or case (any model); and (b) ear buds and boom headsets that transmit mono sound through a wire connection (this does not include ear buds or boom headsets that either transmit stereo sound or that are wireless, or both).
Limited Warranty 6864110r09o.book Page 24 Friday, December 21, 2001 12:04 PM 24 Accessories and software -- call the number designated for the product with which they are used. You will receive instructions on how to ship the Products to Motorola or our designated resource. If instructed to ship the Products, you must ship them with freight, duties and insurance prepaid.
• • • • • • • Rechargeable batteries that: (a) are charged by other than the Motorola-approved battery charger specified for charging such batteries; (b) have any broken seals or show evidence of tampering; (c) are used in equipment other than the Product for which they are specified; or (d) are charged and stored at temperatures greater than 60 degrees centigrade. Any of these voids the warranty.
Limited Warranty 6864110r09o.book Page 26 Friday, December 21, 2001 12:04 PM 26 Flat-rate repair rates may apply to Products not covered by this warranty. To obtain information about Products needing repairs that are not covered by this warranty, please call the telephone number previously listed. We will provide information on repair availability, rates, methods of payment, where to send the Products, etc. VII.
you notifying us promptly in writing when you receive notice of the claim; (b) you giving us sole control of the defense of the suit and all negotiations for its settlement or compromise; and (c) should the Products become, or in Motorola's opinion be likely to become, the subject of a claim of infringement of a United States patent, you permit us, at our option and expense, either to: procure for you the right to continue using the Products; replace or modify them so that they become non-infringing; or gra
Limited Warranty 6864110r09o.
6864110r09o.book Page 29 Friday, December 21, 2001 12:04 PM FCC License Not Required Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software.
6864110r09o.book Page 30 Friday, December 21, 2001 12:04 PM Export Law Assurances Patent Information 30 This product is manufactured under one or more of the following United States patents.
