TABLE OF CONTENT 1. BASIC INFORMATION .................... 5 1.1. BRIEF INTRODUCTION........................................... 5 2. BEFORE USE...................................... 6 2.1. NAME AND EXPLANATION OF EACH PART ............. 6 2.1.1. Appearance Sketch Map ........................... 6 2.1.2. Description of the Standby Pictures .......... 6 2.1.3. Description of Keys .................................. 7 2.2. INSTALL SIM CARD AND MEMORY CARD ............. 9 2.2.1. SIM Card ......................
.2. RECEIVE A CALL ................................................. 13 3.3. END A CALL ........................................................ 13 3.4. EMERGENCY SERVICES ....................................... 14 3.5. EXTENSION SPEED DIAL ..................................... 14 3.6. DIALED CALLS/MISSED CALLS/RECEIVED CALLS/REJECTED CALLS .............................................. 14 3.7. CALL FORWARD .................................................. 14 3.8. CALL WAITING ............................
5. TEXT INPUT..................................... 26 6. CARE AND MAINTENANCE ........ 28 7. HEALTH AND SAFETY PRECAUTIONS .....................................
1. Basic Information 1.1. Brief Introduction Thanks for selecting MOX M340 mobile phone. Through reading the manual, you can fully know how to use M340 mobile phone, appreciate its complete function and simple operating method. M340 mobile phone is designed aiming at GSM/GPRS network environment; the phone is Two Card Two Standby, but you can`t call another SIM card when one SIM card is under phone call.
2. Before Use 2.1. Name and Explanation of Each Part 2.1.1. Appearance Sketch Map The picture is only for your reference. 2.1.2. Description of the Standby Pictures Network signal strength The more the stripe is, the stronger the signal is. When SIM card 1s inserted in card slot 1, standby screen will show the icon. Network signal strength The more the stripe is, the stronger the signal is. When SIM card 1s inserted in card slot 2, standby screen will show the icon.
Silent mode When scene mode is set as mute mode, standby screen will show the icon Meeting mode When scene mode is set as meeting mode , standby screen will show the icon. Indoor mode When scene mode is set as Indoor mode, standby screen will show the icon. Outdoor mode When scene mode is set Outdoor mode, standby screen will show the icon. 2.1.3.
1. Execute functions that the left-down/right-down corner indicator shows. Left soft key/ 2. In the standby mode, press Left Soft Right soft key key to access Menu, Right Soft key to access Contacts. Navigation key On other interfaces, it equals to navigation key and direction key except for special functions. Dial key 1. Press this key to dial or receive an incoming call. 2. When in the standby mode, press this key to access Dialed Calls.
Number key It is used to dial and input numbers or characters. Press and hold Number key 1 or 2 to get through the preset voice inbox. On the standby interface, input *; after inputting telephone number, if you want to input extension number, please press twice asterisk key, after the display screen shows “+”, please input your extension number. *Key # Key 1. In text editing interface, press "#" key to switch text the input method. 2.
provided by network supplier. When you subscribe to a cellular network, you will receive a plug-in SIM card complete with your subscription details, such as your PIN, and available optional services. Caution: Do not bend or scratch your SIM card. Avoid exposing your SIM card to static electricity, water or dirt. Tips：Face the gold color contact point of SIM card towards the cell phone and push the SIM card into the slot. 2.2.2.
connector. Then gently press the battery downward using the finger, and then press the other end to install the battery. Prompt: Please operate correctly to avoid damaging the battery connector. 2.3.2. Charging Insert the charger on the charging interface at the side end of the phone. Connect the charger to a standard wall outlet and the battery power icon in the up-right corner of the screen will start scrolling. When the battery bar stops scrolling, it means the battery charge is complete.
SIM card together. If you input wrong PIN for continuous three times, please input PUK to unlock it. Please contact with network operations company for more details. PIN 2 You need to input PIN2 when entering some functions (such as call charge); if you input wrong PIN2 for continuous three times, you need to input PUK2 to unlock it. Please contact with network operations company for more details. PUK When changing the locked PIN, you need to input PUK (Personal Unlock Key).
3. Quick User Guide 3.1. Dial a Call In standby mode, press numerical keys to input phone number to dial phone number. When you finish inputting phone number, press the dial key to make a call. Reject a Call You can press End key to reject an incoming call. 3.2. Receive a Call When an incoming call arrives, the phone will give out the corresponding prompt (such as vibration, ring tone, and etc.
3.4. Emergency Services You can directly dial an emergency service call without SIM card. Different network uses different emergency numbers, please consult your network operations company for more details. 3.5. Extension Speed Dial After inputting telephone number, if you want to input branch number, please press and hold “*”, input your extension number after the display screen shows “P”. After getting through the call, it will directly dial the extension. 3.6.
Forward Busy, Forward No Answer, Forward Can Not Reach), you can select to switch the incoming call to voice inbox or other telephone numbers. 3.8. Call Waiting After call waiting function is started, when you are calling, the other call can be put through. 3.9.
3.11. T-flash Card Insert the T-Flash card into phone from the background. This will expand the Flash memory of the phone. Tap Multimedia menu, you can browse MP3, MP4, picture, video, photograph etc. 4. Function Menu 4.1. Contacts When this device standby, select [contacts] and open the name list. The contacts are listed in the order of unnamed, special symbol, digit and English letter respectively (for Chinese names, the English letter corresponding to their pinyin prevails). 4.2.
Write message Please have the service center number from the network operator before applying this function. The storage capacity of SIM card depends on its type. ――SMS Under idle situation, press “information service” button to enter into the mailbox list interface, press [Write message →New SMS] to enter into the message editor interface, manual input or insert the contacts from the address list as the recipients, press “send” button to send the messages after editing the contents.
Templates Directly use the default phrases when writing the messages. Settings: Set relevant parameters for the short messages, multimedia messages and push messages. Message capacity: Show the memory capacity of the messages. 4.3. Call logs Call logs Display your recent call log. Missed calls Display the list of your recent missed numbers. The operation is the same as the Dialed. Dialed calls Display the list of your recent dialed numbers.
Rejected calls Display the incoming call records in the blacklist. Delete all You could delete all the records of the Dialed, Received, Missed and Rejected. Call timers Display information details of SIM1/SIM2: Last Call, Received Calls, Dialed Calls, and All Calls. Press left soft key to "Reset". GPRS counter Display information details of SIM1/SIM2: Last sent, Last received, Total sent, and Total received. Press left soft key to "Reset". 4.4.
Dual-SIM: Including Standby mode, Reply by original SIM, Set SIM name, Set dual SIM call divert. Call divert: When “call divert” function is started up, you can transfer the incoming call to voice inbox or other phone number according to the tasked “call divert” conditions. Call waiting: You can start up or shut down the function. When it is started up, even when you are making a call, you can also receive another income call.
Restore factory settings: You can restore part of the phone settings as factory settings. The default code of restoring factory settings is: 0000. Display Wallpaper Settings: Supported: Static wallpaper and more pictures. Idle display settings: Contrast: Adjust the screen backlight. Backlight: Adjust the backlight time. Keypad backlight time: Adjust the keypad backlight time. Security PIN: Start and close of PIN code and the modification of PIN. Modify PIN2: Modification of PIN2 code.
The default anti-theft password is 123456. Fixed dialing: Start and close of the fixed dialing, and management of the fixed dialing list Blacklist: Set the Settings of the blacklist and management of the list. Connections The items are: Network account: Manage internet account, and support editor and delete. GPRS Service: Choose turn on or off GPRS service. Data connection settings: Select to connect as needed or all the time. Network selection: Select to automatically or manually connect. 4.5.
installed when the video capture function is used. The details can be found in driver installation guide. Image Check the pictures and shoot photos in the memory card through the photo album. Audio This phone could play the MP3 stored in the phone memory and support the background play.Press the navigation key into the song list.Press OK to play or pause, press the navigation button to stop playing. Press up key and down key to adjust volume.
The record file format: wav. File Manager files manager can manage the files in the memory card. (make sure the card has been inserted). Games This mobile phone provides, Sokoban ,snake , Bubblebobble and Tetris four small game, please see the in-game help illustrate specific operation 4.6. Organizer Calendar You can use this feature to view the year, date and solar term easily. Use up/down/left/right direction key to navigator other date.
Torch You can turn on/off torch light or long press 0 key in standby interface. BT E-book 4.7. Profiles The preset modes are Normal mode, Silent mode, Meeting mode, Indoor mode, Outdoor mode and Earphone mode.It support custom profiles, define at most 5 profiles, and users can set the parameters of the profiles. Instruction: The preset profiles do not support delete, while the custom profiles support delete. More Functions Choose one mode, to open the option menu: Rename:Rename the current mode.
& calendar remind. Other alert rings: Set the other alert rings, such as Key tone, Battery low alert, Power ring tone, Dial tone. 4.8. Internet The device is compatible with WAP service. You can visit various WAP services, for instance, news, weather forecast and airlines etc. The services are specially designed for the device and are maintained by WAP service supplier. WAP service requires network backup.
Letter (Capital, Normal) Enter edit page, press “#”and switch the input mode to “letter”, then press the keys on keypad, selected letters will appear on the screen. Press the number key can get the first letter marked on the key, press twice quickly can get the second letter marked on the key. Similarly, if the letter you want to input have the same key with the former letter, please wait until the cursor appears again, then input the new letter.
6. Care and Maintenance Maintenance of battery ·Your device is powered by a rechargeable battery. It is necessary to have the battery charged when it is going to wear out. The full performance of a new battery is achieved only when it is fully wore out. ·Unplug the charger from the electrical plug and the device when not in use. Do not leave fully a charged battery connected to a charger over a week, since overcharging may shorten its lifetime.
·Do not dispose of batteries in a fire as they may explode. Dispose of batteries according to local regulations. Care of maintenance of your device The suggestions below will help you protect your warranty coverage. ·Keep the device and accessories out of the reach of small children. ·Keep the device dry. All types of liquids or moisture will corrode electronic circuits. · Do not store the device in hot areas. High temperatures can shorten the life of electronic devices and warp or melt certain plastics.
e-waste Rules: 1. Lead (Pb) – not over 0.1% by weight; 2. Cadmium (Cd) – not over 0.01% by weight; 3. Mercury (Hg) – not over 0.1% by weight; 4. Hexavalent chromium (Cr6+) – not over 0.1% by weight; 5. Polybrominated biphenyls (PBBs) – not over 0.1% by weight; 6. Polybrominated diphenyl ethers (PBDEs) – not over 0.1% by weight. 7. Health and Safety Precautions Please read these simple guidelines. Not following them may be dangerous or illegal.
laboratory tests. The SAR value of the phone may depend on factors such as proximity to the network tower, use of accessories or other accessories. The highest SAR value of the M340 is 0.479 W/kg averaged over 1 gm of human tissue. SAR Recommendations Please keep your calls short and use SMS whenever more convenient. This advice applies especially to children, adolescents and pregnant women Prefer to use your cell phone when the signal quality is good.
emergency braking. During Flight Flight is influenced by interference caused by the phone. It is illegal to use a phone on the airplane. Please turn off your phone during a flight. In Hospitals Your Phone’s radio waves may interfere with the functioning of inadequately shielded medical devices. Consult a physician or the manufacturer of the medical device to determine whether they are adequately shielded from external Radio Frequency. Switch off your device when regulations posted instruct you to do so.
Please turn off your phone when you are close to a gas station or in the vicinity of any place where fuel and chemical preparations, or any other dangerous goods are stored. Limited Warranty Terms and Conditions This warranty is valid for the Paraguay. For other countries please refer to the local legislation or distributor. Repair Guarantee 12 months.
MOX SA is liable for any lack of conformity which exists at the time the goods were delivered during a period of 12 months, under the terms and conditions set out below. This warranty covers any defects in workmanship or materials. This warranty doesn’t cover any failure of the product due to accidents, misuse or alteration made by an unauthorized person. This warranty doesn’t cover any failure and damage caused by fire, earthquake, lightning, flood and other natural disaster.
Batteries are excluded from this warranty, having a warranty period of 3 months. During the 12 months after purchase the customer will be required to ship the device to MOX Technical Service by the means the client deems most appropriate and at his expense. As far as possible the client will send the device to MOX Technical Service in its original box and with the accessories included at the time of purchase.
If within 3 days after the purchase, the product has a manufacturing defect MOX will replace the product for a totally new unit of the same model. If for reasons of stock is not possible to do the replacement for the same model, this one would be carried out for a model of equal or higher performance than the original product. This management will not cause any type of expense for the customer.
FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: This GSM MOBILE PHONE meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies.
handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 10mm must be maintained between the user’s body and the handset, including the antenna.
