OnCell 5000 Series Configuring OnCell Central Management Software
7-2
Step 1: Server Settings
System Requirements
Hardware Requirements
Your computer’s hardware must meets the following minimum requirements:
• Pentium III or above
• 500 MHz CPU (1 GHz recommended)
• 256 Mb RAM (1 GB recommended)
• 300 MB disk space
Software Requirements
OnCell Central Manager runs on the following operating systems:
• Microsoft Windows 2000 Server
• Microsoft Windows Server 2003
• Microsoft Windows Server 2008
• Internet Explorer 6.0 above is required.
Installation Requirements
Installing OnCell Central Manager software involves two main elements:
• Adobe Flash
• OnCell Central Manager software
Installing OnCell Central Manager
To install the OnCell Central Manager software, follow these steps. This procedure requires that you have
administrative privileges. Insert the OnCell Installation CD into the OnCell Central Server.
1. Click the INSTALL OnCell Central Manager button in the OnCell Installation CD auto-run window to
install the OnCell Central Manager. Once the installation program starts running, click Yes to proceed.
OnCell
Device
OnCell
Central
Manager
OnCell Central
Server
Devices
Host
Ethernet Device
Step 3
Step 2
Ethernet
Step 1
