User`s manual

OnCell 5000 Series Introduction
1-3
• 2 digital inputs and 1 relay output (OnCell 5104 series only)
Product Specifications
Specification Comparison Chart
OnCell
5004/5104
OnCell
5004/5104-HSDPA
OnCell
5004/5104-HSDPA-JPS
5004/5104-HSDPA-JPN
Cellular Interface
Standards GSM/GPRS GSM/GPRS/EDGE/UMTS/
HSDPA
UMTS/HSDPA
Quad-band Options Quad-band
850/900/1800/1900
MHz
Tri-band 850/1900/2100 MHz
Quad-band
850/900/1800/1900 MHz
2100 MHz
GPRS Multi-slot Class 10 -
GPRS Terminal Device Class B -
GRRS Coding
Schemes
CS1 to CS4 -
Tx Power 1 watt GSM1800/1900, 2
watt EGSM850/900
1 watt GSM1800, 2 watt
GSM900, 0.25 watt
UMTS/HSDPA, 0.5 watt
EDGE900, 0.4 watt EDGE1800
0.25 watt UMTS/HSDPA
WAN Interface
Number of Ports 1
Ethernet 10/100M (RJ45)
1.5 KV Magnetic
Isolation Protection
Yes
LAN Interface
Number of Ports 4
Ethernet 10/100M (RJ45)
1.5KV Magnetic
Isolation Protection
Yes
SIM Interface
Number of SIMs 2
SIM Control 3V
I/O Interface
Alarm Contacts &
Digital Inputs
OnCell 5004 series: No I/O interface
OnCell 5104 series: 1 Digital Output & 2 Digital Inputs
Software
Network Protocols UDP/TCP, SNTP, ICMP, DDNS, DHCP/BOOTP, PPPoE, PPP, DNS, Relay, HTTPS, Telnet
Router/Firewall NAT, port forwarding, routing
Authentication Local user-name and password
Security IP filtering
Physical Characteristics
Housing Aluminum (IP30)
Weight OnCell 5004 series: 505 ± 5 g
OnCell 5104 series: 645 ± 5 g
Dimensions OnCell 5004 series: 158 x 103 x 34 mm
OnCell 5104 series: 160 x 103 x 50 mm
