User`s manual

OnCell 5000 Series Introduction
1-4
Environmental Limits
Operating
temperature
-30 to 55°C (-22 to 131°F), 5 to 95% RH
Storage Temperature -40 to 75°C (-40 to 167°F)
Regulatory Approvals
Safety UL (UL60950) -
Radio FCC Part 22H, FCC Part 24E, EN301 489-1, EN301 489-7
EN301 511
VCCI
EMC CE: EN55022 Class A / EN55024, FCC: FCC part 15
subpart B, Class A, EN61000-4-2 (ESD) Level 4,
EN61000-4-3 (RS) Level 3, EN61000-4-4 (EFT) Level 4,
EN61000-4-5 (Surge) Level 3, EN61000-4-8 Level 3,
EN61000-4-12 Level 3
-
Reliability
Warranty 5 years (see www.moxa.com/warranty for details)
OnCell 5004/5104
Cellular Interface
Standards: GSM/GPRS
Band Options: Quad-band 850/900 and 1800/1900 MHz
GPRS Multi-slot Class: Class 10
GPRS Terminal Device Class: Class B
GPRS Coding Schemes: CS1 to CS4
Tx Power: 1 watt GSM 1800/1900, 2 watts EGSM 850/900
WAN Interface
Number of Ports: 1
Ethernet: 10/100 Mbps, RJ45 connector, Auto MDI/MDIX
Magnetic Isolation Protection: 1.5 KV built-in
LAN Interface
Number of Ports: 4
Ethernet: 10/100 Mbps, RJ45 connector, auto MDI/MDIX
Magnetic Isolation Protection: 1.5 KV built-in
SIM Interface
Number of SIMs: 2
SIM Control: 3 V
I/O Interface (OnCell 5104 only)
Alarm Contact: 1 relay output with current carrying capacity of 1 A @ 24 VDC
Digital Inputs: 2 electrically isolated inputs
• +13 to +30 V for state “1” (On)
• +3 to -30 V for state “0” (Off)
Software
Network Protocols: UDP/TCP, SNTP, ICMP, DDNS, DHCP/BOOTP, PPPoE, PPP, DNS Relay, HTTPS, Telnet,
IPSec
Router/Firewall: NAT, port forwarding, routing
Authentication: Local user-name and password
Security: IP filtering
Management Software
OnCell Central Manager: Centralized management solution for accessing private IPs from the Internet
