User`s manual

ManualsBrandsMoxa ManualsNetworkingONCELL G3111

179

180

181

182

183

184

185

186

187

188

Table Of Contents

1. Introduction
- Overview
- Package Checklist
- Product Features
- Product Specifications
2. Getting Started
- Panel Layout
  - OnCell G3111/G3151/G3211/G3251
- Connecting the Hardware
3. Initial IP Address Configuration
- Static and Dynamic IP Addresses
- Factory Default IP Address
- Configuration Options
4. Introducing Serial Port Operation Modes
- Overview
- Device Control Applications
- Socket Applications
- Ethernet Modem Mode
- SMS Tunnel Mode
- Disabled Mode
5. Introducing OnCell Central and Ethernet Operation Modes
- OnCell Central Management Software
- OnCell Central Serial Device Connection
- OnCell Central Ethernet Device Connection
- Cellular-Enabling Ethernet Device
6. Using the Web Console
- Using Your Web Browser
- Web Console Navigation
- Basic Settings
  - Server Settings
  - Time Settings
- Network Settings
- GuaranLink Settings (Pending)
7. Cellular Network Settings
- GSM GPRS Settings
8. Configuring Serial Port Operation Modes
- Port Setting Basics
- Device Control Applications
- Socket Applications
- Ethernet Modem Mode
- SMS Tunnel Mode
- Disabled Mode
9. Configuring the Cellular-Enabling Ethernet Device
- Host to OnCell via Cellular
10. Configuring OnCell Central Management Software
- Step 1: Server Settings
- Step 2: OnCell Device Web Console Settings
  - OnCell Central Settings
  - OnCell Central Server
- Step 3: Host Settings and Management
  - OnCell Central Web Console
- Server
- Device
- Logout
11. Additional Serial Port Settings
- Port Communication Parameters
- Serial Parameters
- Port Data Buffering/Log
- Port Chipher Settings
12. System Management Settings
- Misc. Network Settings
- Auto Warning Settings
- Maintenance
- Certificate
  - Ethernet SSL Certificate Import
  - Certificate/Key Delete
- System Monitoring
- System Status
  - Serial Data Log
  - System Log
- Network Status
- Save Configuration
- Restart
  - Restart System
  - Restart Ports
13. Software Installation/Configuration
- Overview
- OnCell Windows Driver Manager
  - Installing OnCell Windows Driver Manager
  - Using OnCell Windows Driver Manager
- OnCell Search Utility
  - Installing OnCell Search Utility
  - Configuring OnCell Search Utility
- Moxa OnCell Linux Real TTY Driver
- Moxa OnCell UNIX Fixed TTY Driver
  - Installing the UNIX Driver
  - Configuring the UNIX Driver
A. Pinouts and Cable Wiring
- Port Pinout Diagrams
  - RS-232 (male DB9) Pinouts
  - RS-232/422/485 (male DB9) Pinouts
- Cable Wiring Diagrams
  - Serial Cables
  - Pin Assignments for DB9 and DB25 Connectors
B. RFC2217
C. Dynamic Domain Name Server
- Overview
- Configuration
D. Well Known Port Numbers
E. Auto IP Report Protocol
F. GSM Alphabet
G. Default Settings

Appendix G Default Settings

OnCell G3111/G3151/G3211/G3251 and OnCell Central Default Settings

Setting Name Default Name

Web Console Login

Username admin

Password Keep <blank>

Network Settings

IP configuration Static

IP address 192.168.127.254

Network 255.255.255.0

WINS function Enable

LAN speed Auto

GSM/GPRS Settings

Type GSM

SIM PIN <blank>

Band Auto

GSM Operation Mode

Modes PPP

TCP/IP Compression Disable

Inactivity Time 0

Link quality report Disable

Connection Control Always On/None

Connection Interval 5 min

GPRS Operation Mode

TCP/IP Compression Disable

Inactivity Time 0

Link quality report Disable

Connection Control Always On/None

Connection Interval 5 min

Real COM Mode

Data port 950

Command port 966
