OnCell G3111/G3151/G3211/G3251 Series User’s Manual Initial IP Address Configuration

3-2

Static and Dynamic IP Addresses

Determine whether your OnCell G3111/G3151/G3211/G3251 needs to use a static IP address or

dynamic IP address (either DHCP or BOOTP application).

 If your OnCell G3111/G3151/G3211/G3251 is used in a static IP environment, you must

assign a specific IP address using one of the tools described in this chapter.

 If your OnCell G3111/G3151/G3211/G3251 is used in a dynamic IP environment, the IP

address will be assigned automatically from over the network. In this case, set the IP

configuration mode to DHCP or BOOTP.

ATTENTION

Consult your network administrator on how to reserve a fixed IP address for your OnCell

G3111/G3151/G3211/G3251 in the MAC-IP mapping table when using a DHCP Server or

BOOTP Server. For most applications, you should assign a fixed IP address to your OnCell

G3111/G3151/G3211/G3251.

Factory Default IP Address

The OnCell G3111/G3151/G3211/G3251 is configured with the following default private IP

address:

192.168.127.254

Note that IP addresses that begin with “192.168” are referred to as private IP addresses. Devices

configured with a private IP address are not directly accessible from a public network. For example,

you would not be able to ping a device with a private IP address from an outside Internet connection.

If your application requires sending data over a public network, such as the Internet, your OnCell

G3111/G3151/G3211/G3251 will need a valid public IP address, which can be leased from a local

ISP.

Configuration Options

OnCell Search Utility

You may configure your OnCell G3111/G3151/G3211/G3251 with the bundled OnCell Search

Utility for Windows. Please refer to Chapter 11, Software Installation/Configuration, for details on

how to install and use OnCell Search Utility.

Web Console

You may configure your OnCell G3111/G3151/G3211/G3251 using a standard web browser. Please

refer to Chapter 5, Using the Web Console, for details on how to access and use the OnCell

G3111/G3151/G3211/G3251 web console.

ARP

You may use the ARP (Address Resolution Protocol) command to set up an IP address for your

OnCell G3111/G3151/G3211/G3251. The ARP command tells your computer to associate the

OnCell G3111/G3151/G3211/G3251’s MAC address with an IP address. Afterwards, use Telnet to

access the OnCell G3111/G3151/G3211/G3251 and its IP address will be reconfigured.
