OnCell G3111/G3151/G3211/G3251 Series User’s Manual Cellular Network Settings
7-3
PPP Mode: PPP provides standard PPP dial-out service.
PPPD Mode: PPPD (PPP Daemon) is used for dial-in services, since it provides PPP services only
when receiving a request from a remote PC.
Destination IP address:
Source IP address:
IP netmask:
If you do not configure these three parameters, they will be filled in
automatically by the remote side of the connection.
TCP/IP compression (default=Disable): The setting of this field depends on whether the remote
user’s application requests compression.
Inactivity time (default=0 ms): This field specifies the idle time setting for auto-disconnection. A
setting of 0 ms will cause the port to remain connected even if idle.
Link quality report (default=Disable): Setting this field to Enable allows the OnCell
G3111/G3151/G3211/G3251 to disconnect a connection if the link noise exceeds a certain
threshold.
Outgoing PAP ID: This is the dial-out user ID account.
PAP password: This is the dial-out user password.
Incoming PAP check (default=None): This field allows you to configure the method used, if any,
to verify a user’s ID and authorization.
Option Description
Local
Verify the ID against the OnCell G3111/G3151/G3211/G3251
password. The user name for the OnCell
G3111/G3151/G3211/G3251 is fixed to “admin.”
None
Authentication is not required.
Phone number: Use this field to configure the number used to dial out.
Connection control Connect Rule Disconnect Rule GSM
Always on/None Always on after power on None
Trunk
Periodically
connect/inactivity time
Periodically connect (based on the
connection interval setting) to
GSM after power on.
Inactivity time is up
Trunk
Remote host fail/remote
host recovered
Remote Ethernet host has failed.
The OnCell
G3111/G3151/G3211/G3251 will
keep pinging the remote host over
the Ethernet every 3 seconds after
powering on. After failing to
connect 5 times in a row, the data
from the serial device will be sent
through the GSM connection.
When the remote
Ethernet host returns
to normal, data will
revert to being sent
over Ethernet after 5
continuous
successful pings.
Backup
Connection interval (default= 5 min): The time interval of the periodically connect function.
Ping remote host: Key in the IP address or Domain name of the remote host.
