VPort CGI Commands VPort Set/Get Configuration CGI URL and Parameter Items
2-11
multicast
This section describes the RTSP multicast address group parameter settings for Moxa VPort 1-channel video
encoders and IP cameras.
VPort 251/351/25/15 items
Item Action Value Description
ipaddress G/S xxx.yyy.zzz.www Media multicast IP address
videoport G/S
1024 to 65535 (The video and audio
port numbers must be at least 2
integers apart)
Video multicast port number
audioport G/S
1024 to 65535 (The video and audio
port numbers must be at least 2
integers apart)
Audio multicast port number
ttl G/S 1 to 255 TTL value of multicast packet
VPort 451/461/06/16/26/36 items
Item Action Value Description
ipaddress01,
ipaddress02
G/S xxx.yyy.zzz.www Media multicast IP address
videoport01,
videoport02
G/S 1024 to 65535 (video port & audio
port;
must be separated by at least 2)
Video multicast port number
audioport01,
audioport02
G/S 1024 to 65535 (video port & audio
port;
must be separated by at least 2)
Audio multicast port number
(Only valid for models with the audio
feature)
ttl01,
ttl02
G/S 1 to 255 TTL value of multicast packet
VPort 451/461/16/26 support multiple H264 streaming: 01 indicates the first video stream and 02
indicates the second video stream.
multicast##
This section applies to 4-channel video encoders; “##” indicates the channel number of the video encoder (01
to 04). For example: multicast02_ipadress is the multicast group address of channel 2.
Item Action Value Description
ipaddress G/S xxx.yyy.zzz.www Media multicast IP address
videoport G/S
1024 to 65535 (The video and audio
port numbers must be at least 2
integers apart)
Video multicast port number
audioport G/S
1024 to 65535 (The video and audio
port numbers must be at least 2
integers apart)
Audio multicast port number
ttl G/S 1 to 255 TTL value of multicast packet
video
This section describes CGI commands for 1-channel video encoders and IP cameras.
For example, the CGI command format to get information about the video is:
http://<server>/moxa-cgi/getparam.cgi?video_text
The CGI command format for setting the video resolution is:
http://<server>/moxa-cgi/setparam.cgi?video_size=1
