VPort CGI Commands VPort Set/Get Configuration CGI URL and Parameter Items
2-16
video##
This section applies to 4-channel video encoders; “##” indicates the channel number of the video encoder (01
to 04), for example:
To get the information about the channel 2 video, the CGI command format:
http://<server>/moxa-cgi/getparam.cgi?video02_text
To set the size of channel 4 video resolution, the CGI command format:
http://<server>/moxa-cgi/setparam.cgi?video04_size=1
VPort 254/VPM7304/VPort 354/VPort 364/VPort 364A/MxMVR-MO4 items
Item Action Value Description
text G/S Max 14 char (ExtensiveString) Information about the video
imprinttimestamp G/S 0: Not Shown
1: Shown in the caption
2: Shown in the image
The location of shown video
information
codectype G 1,[1,1,(1,1)]: MPEG4
1,[1,1,(1,2)]: MJPEG
Video codec type selection for
VPort 254/ VPM7304
1,[1,2,(1,1),(2,2)] Video codec type selection for
VPort 354
1,[1,1,(1,6)] Video codec type selection for
VPort 364
Size G/S 1: 720x480(NTSC), 720x576(PAL)
2: 640x480(NTSC), 640x576(PAL)
3: 352x240(NTSC), 352x288(PAL)
4: 320x240(NTSC), 320x288(PAL)
5: 704x480(NTSC), 704x576(PAL)
Video resolution for VPort 254/
VPM7304
If Frame Rate Mode is used, only
352x240(288) and 320x240(288)
resolutions are supported.
size G/S 3: 352x240(NTSC), 352x288(PAL)
5: 704x480(NTSC), 704x576(PAL)
6: 704x240(NTSC), 704x288(PAL)
7: 224x160(NTSC), 224x192(PAL)
8: 176x112(NTSC), 176x144(PAL)
Video resolution for VPort 354
size01_h264
size01_mjpg
G/S 1: 720x480(NTSC), 720x576(PAL)
2: 640x480(NTSC), 640x480(PAL)
3: 352x240(NTSC), 352x288(PAL)
5: 704x480(NTSC), 704x576(PAL)
8: 176x112(NTSC), 176x144(PAL)
Video resolution for VPort 364
maxframe G/S NTSC
Frame Rate Mode:1, 3, 5, 10, 15, 30
Resolution Mode:1, 2, 3, 7
PAL
Frame Rate Mode:1, 3, 5, 8, 12, 25
Resolution Mode:1, 2, 3, 6
Maximum frame rate (fps) for
VPort 254 and VPM7304
maxframe G/S NTSC
1, 3, 5, 10, 15, 20, 25, 30
PAL
1, 3, 5, 8, 12, 16, 20, 25
Maximum frame rate (fps) for
VPort 354
maxframe01_h264
maxframe01_mjpg
G/S NTSC
h264: 1, 3, 5, 10, 15, 20, 25, 30
mjpeg: 1,3,5,10,15
PAL
h264: 1, 3, 5, 8, 12, 16, 20, 25
mjpeg: 1, 3, 5, 8, 12
Maximum frame rate (fps) for
VPort 364
The frame rate setting h264 and
mjpg will depend on each other.
keyinterval G/S 5, 15, 30, 60, 90 Key frame interval for VPort 254
and VPM7304
keyinterval G/S 5, 15, 30, 60, 90 Key frame interval for VPort 354
