NPort W2004 User’s Manual Web Console Configuration
5-15
Command port
Setting Factory Default Necessity
1 to 65535 966 Optional
The “Command port” is a listen TCP port for IP-Serial Lib commands from the host. In order to
prevent a TCP port conflict with other applications, the user can set the Command port to another
port if needed. IP-Serial Lib will automatically check the Command Port on NPort W2004 so that
the user does not need to configure the program.
TCP Client Mode
Port 1/2/3/4
TCP alive check time
Setting Factory Default Necessity
0 to 99 min 7 min Optional
0 min: TCP connection is not closed due to an idle TCP connection.
1 to 99 min: NPort W2004 automatically closes the TCP connection if there is no TCP activity for
the given time. After the connection is closed, NPort W2004 starts listening for another host’s
TCP connection.
Inactivity time
Setting Factory Default Necessity
0 to 65535 ms 0 ms Optional
0 ms: TCP connection is not closed due to an idle serial line.
