NPort W2004 User’s Manual Web Console Configuration
5-18
UDP Mode
Data Packing
Delimiter 1/2
Setting Factory Default Necessity
00 to FF (hex) None Optional
Once the NPort W2004 receives both delimiters through its serial port, it immediately packs all
data currently in its buffer and sends it to the NPort W2004’s Ethernet port.
ATTENTION
Delimiter 2 is optional. If left blank, then Delimiter 1 alone trips clearing of the buffer. If the size
of the serial data received is greater than 1 KB, the NPort W2004 will automatically pack the
data and send it to the Ethernet. However, to use the delimiter function, you must at least enable
Delimiter 1. If Delimiter 1 is left blank and Delimiter 2 is enabled, the delimiter function will not
work properly.
Force transmit
Setting Factory Default Necessity
0 to 65535 ms 0 Optional
0: Disable force transmit timeout.
1 to 65535: Forces the NPort W2004’s TCP/IP protocol software to try to pack serial data received
