For Model No.
Tablet Part MPQC91 8GB 3 5 ESC 6 MIC USB 4 MADE IN PRC 2 Internet Mobile Device with Android OS RESET 1 7 Name Power function Keep pressed to turn on/off the tablet; shortly press to activate standby Reset Tablet will force to shutdown Earphone jack Connect earphone to this standard 3.
Getting Started Battery Charging The tablet has a built-in rechargeable Li-polymer battery. 1. To charge connect the AC power adapter to the micro USB jack on the right side of the tablet. 2. The battery icon shows the battery status and charging status 3. The tablet can be used even if the battery is being charged. the above icons indicate the different level of electricity left in the battery 4. no replacement of battery without authorization, or the explosion hazard might happen. 5.
recycling-station before disposing the tablet pc, and don’t litter. Power ON/OFF ON: press the OFF: button for continuous 5 seconds until the tablet turns “ON”. 1.Press the button for continuous 5 seconds and it will appear 2.Select OK to power off the tablet Screen Lock This feature locks the screen, at the same time turn OFF the screen’s backlight after a few seconds. Screen locks when: 1. System is idle. 2. Manually activated by pressing the Power button once.
The Desktop cn contains shortcuts to your most-used applications and widgets Touch the screen icon to quickly search the World Wide Web using Google. The icon will launch the Application menu. The status bar displays system information, such as current time, wireless connectivity and battery. Touch to Expand the status bar for more detailed information. The button moves back one step to the previous menu/page. The buttons returns immediately to the Android desktop.
1. Touch the "Settings" menu icon on the Application menu.The Settings menu will open. 2. Guide your finger up or down the left side of the screen to scroll through the list of available categories. 3. Touch a category title to view further options on the right side of the screen.
the TF card. 2. Select “Setting” and find “ Storage” then click “Unmount SD card”. 3. A prompt will be seen on the screen saying “ SD card safe to remove” 4. Gently press the TF card to remove and pull out the TF card. Note: Insert the TF card in correct position, otherwise it will damage the card and the slot. Software Keyboard The tablet has a software keyboard which automatically show up when you tap the place on screen where text or number are to be entered.
Connection to Internet Wireless: 1 Select “ Settings” 2 Select “Wi-Fi” and slide OFF to ON status. 0FF 3 4 5 ON All detected wireless networks in the area will be listed, Click to select desired wireless connection. Once connected to a wireless network, settings will be saved Wireless icon will appear on the taskbar when connected successfully. Note: when the tablet detects the same wireless network in the future, the device will connect to the network automatically with same password record.
Web Browsing Connect to the internet and launch the browser.
1. Touch the icon 2. Move the icon in the middle to take photo on bottom and you can switch camera mode to camera recording mode. 3. touch the icon on the top right to see the previous picture and you can also delete, share, set it as the wallpaper. Click return button to exit camera interface. Trouble Shooting Close Application All running applications take up system memory and will slow down system response.
Tap the application you want to close. A pop-up window will be displayed. Tap “Stop” to close that application. Mandatory Power off 1. Press and hold the power button for 5 seconds and the device will be powered off. 2. Press the reset button on the back and the device will be forced to be powered off. Restore Default Setting If you want to reset the factory setting and erase all materials, please press Settings → Backup & reset → Factory data reset.
For more information please cheeck our website www.mpmaneurope.
