For Model No.
1:Buttons 1. 2. 3. 4. 5. 6. 7. 8. Earphone jack DC jack USB Port1 USB Port2 TF card slot Power button: Press briefly to sleep/wake. Press and hold to turn on/off.
2. Safety Read these simple guidelines. Not following them may be dangerous or illegal. switch off in restricted areas Switch the device off when mobile Tablet use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. road safety comes first Obey all local laws. Always keep your hands free to operate the vehicle while driving.
batteries, chargers, and other accessories Use only batteries, chargers, and other accessories approved by S805G for use with this device. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to your device micro USB connector, may be compatible. Do not connect incompatible products. keep your device dry Your device is not water-resistant. Keep it dry. glass parts The device screen is made of glass.
4. Charge your Tablet Learn how to charge your Tablet. Your battery has been partially charged at the factory, but you may need to recharge it before you can switch the Tablet on for the first time. Make sure you use a compatible USB charger to charge your Tablet. 1. First connect the USB cable to the charger, and plug the charger into a wall outlet, then connect the micro-USB end of the cable to your Tablet. 2. When the battery is full, disconnect the charger from the Tablet, then from the wall outlet.
5. First start-up Learn how to get your new Tablet up and running. Your new Tablet comes with great features that will be installed when you start your Tablet for the first time. Allow some minutes for your Tablet to be ready. Switch the Tablet on Are you ready? Switch your Tablet on, and start exploring it. Press and hold the power key until the Tablet vibrates. Switch the Tablet off Press and hold the power key, and drag the lock screen down. 6.
. Create your Microsoft account Spice up your life and get more from your Tablet – create a Microsoft account. To create a Microsoft account, you need an internet connection. If you don't have a data plan, the data transmission costs may pile up quickly. For info about possible data costs, contact your network service provider. If you can't connect to the internet, you can create the account later. 1. To set up your Tablet, follow the instructions shown on the screen. 2.
Networking applications View the latest information, and began chatting with your email account, Facebook, LinkedIn, Messenger, Twitter and more account of contact. Photo application View all your photos and video from the same location, whether they are located on Facebook, Flicks, OneDrive, or on another Tablet.
Message application Send a message to your Facebook and Messenger friends unified list, and select hundreds of emoticons. Music application Browse your music collection, create and edit playlists, and find the most popular new music. To view detailed information that including pictures of the artist biographies and album list. Registered Xbox music, in this way you can access to unlimited right to hear mass songs.
OneDrive application Other equipment access your files from your Windows application seamlessly. Mail application In the same position, to receive your email from Outlook.com, Gmail and Yahoo, account. Video application On your Tablet , watching movies and TV shows, or broadcast to your TV.
Weather application Use the weather application to view a picture of beautiful preview of current weather conditions. You can check the latest situation as well as hourly, daily and 10 days of forecast information. Games application Discover the hottest new games and download them to your Tablet. Depending on where you live and travel you can edit your avatar to view your buddy's dynamic, and share with them what you get.
Calendar application In the two-day view, week view, or month view to keep track of your schedule. At the right moment to get notification about the date, so you will always be on time for the meeting. Finance application Use this application to see the main market index, and from the "start" screen master recent developments in the rapidly changing market conditions. Travel application Through beautiful pictures, a mysterious veil over 2000 destinations worldwide.
9. Touch-screen Navigation Use your fingers to manipulate icons, buttons, menus, the onscreen keyboard, and other items on the touch screen. You can also change the screen's orientation. To select or activate something, touch it. To type something, such as a name, password, or search terms, just touch where you want to type. A keyboard will pop up onscreen, allowing you to type.
Swipe from the left of the screen，will show the previously used application Swipe from the left of the screen will display the most recently used application, you can select from the list. Swipe from the top or bottom edge displays the apply command. You can swipe the top or bottom edgeof the screen to displays the apply command. Then to dock or to close the current application. Drag the application to close You don't have to close the application.
Keeping press for details In some cases, keeping press menu can be opened to provide more options. Click to perform actions Click on some of the content will trigger some action, such as opening an application or to a link. Dragging the scroll This action is mainly used for panning or scrolling the lists and pages, it also can be used for other interactions, such as painting , writing or moving an object.
The zoom feature allows you to skip to the top of the list, at the bottom, or any particular location. You can use two fingers on-screen shrink or stretch to zoom. Flip by rotating Rotates two or more fingers may turn over an object. You may when rotates the equipment, the entire screen revolves 90 degrees. 10.Operation Scales the shrinking or stretching.
fingers sliding back and forth you can search. These operations can be done easily with the mouse. Switching from swipe to the left to recently used applications. You can conduct operations will be based on your location and change and, therefore, let us know. Search, share, start, equipment and settings are always on the right side of your screen. Through touch, swipe the edge from the right, and then click what you want to get the content.
17
1. Search for any content anywhere, anytime. You can search only the application you are using, for example, find a message in a mail application, or find an application in the app store, search for another application, search for an application, or your entire Tablet settings or files. 2. Completely without leaving your current applications can share files and information with people you know, or send information to another application.
Touch pad has two modes, so you can full size keyboard that contains large buttons and split button on the side of the screen and easy switching between the thumb keyboard. Whether you are sitting or walking, every touch keyboard lets you type becomes more convenient, comfortable and natural.
12. Define internet connections Does your network service provider charge you a fixed fee for data transfer or on a pay-as-you-use basis? Change the Wi-Fi and mobile data settings to reduce your data costs while roaming and at home. Important: Use encryption to increase the security of your Wi-Fi connection. Using encryption reduces the risk of others accessing your data. Using a Wi-Fi connection is generally faster and less expensive than using a mobile data connection.
13. Take care of your device Handle your device, battery, charger and accessories with care. The following suggestions help you keep your device operational. • Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode electronic circuits. If your device gets wet, let the device dry. • Do not use or store the device in dusty or dirty areas. • Do not store the device in high temperatures. High temperatures may damage the device or battery.
MPWIN110CL Keyboard User Manual 1.
2.
Two fingers from the middle to both sides of the slide - amplifier (similar to hold down the Ctrl key while scrolling the mouse wheel) A finger swipe from right to left - out Win8 Charm menu (similar to the "Win+c" key) Two-finger pinch Swipe in from the sight edge Zoom(Ctrl+Mouse wheel) Toggle the charms(Windows logo key+C) Fingers from sliding down, close the current program (similar to the "Win+z" key) The finger from left to right - sliding switch to the next application (like "Win+Ctrl+ backspace"
3. electrical parameters definition of electrical items The definition of value The definition of matters The definition of value Work voltage 4.75V~5.25V Current keyboar d ≤2.
