OPERATING INSTRUCTIONS FOR @ THE ICED TEA POTTM BY MR. COFFEE SERIES TMWTMlO MR.
IMPORTANT SAFEGUARDS When using electrical appliances, basic precautions should always be fol lowed to reduce the risk of fire, electric shock and/or injury to persons, including the following: 1. Readall instructions before using the machine. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against electric shock, do not immerse or rinse cord, plugs, Qt-pfbrewerinwaternratherliauid. 4. Close adult supervision is necessary when this appliance is used by or near children. 5.
SPECIAL CORD SET INSTRUCTIONS 1. A short power supply cord is provided to reduce the hazards resulting from becoming entangled in or tripping over a longer cord. 2. An extension cord may be purchased and used if care is exercised in its use. 3. If an extension cord is used, the marked electrical rating of the extension cord must be at least 10 amps and 120 volts.
Introduction Congratulations! You are the owner of The Iced Tea Potw by Mr. Coffee’ Series TM!VTMlO, 2-l/2 quart iced tea maker. This unique appliance has been designed to provide you with excellent tasting iced tea quickly and conveniently. Our specially designed brewer heats water and steeps tea to extract the full flavor from your tea. Afterbreuuma. and d&nses &a . . the r&&&j with tee to &L ’ As a result, you get consistently great tasting, fresh brewed iced tea every time.
Table of Contents . Important Safeguards .....................................................................................2 Cord Set Instructions ......................................................................................3 Introduction ....................................................................................................4 If Service is Required .....................................................................................4 Diagram of Parts ..............................
C/eaning Your Iced Tea Pot Before First Use Please clean your unit prior to first use (or when unit has not been used for some time). 1. First unplug unit from electrical outlet. Wash the pitcher and lid with warm water and mild detergent. Rinse thoroughly. Wipe exterior and brewer with a soft, damp cloth, then dry with a soft towel. DO NOT use abrasive cbarr ers or metal scouring pads. Do NOT IMMERSE OR RINSE UNDERSIDE OF BREWER IN WATER. NO PARTS ARE DISHWASHER SAFE. 2.
Using The Iced Tea Pot TM To brew lced Tea: 1. Prior to first use, clean unit according to instructions in section “Cleaning Your iced Tea Pot Before First Use’, on page 6. 2’ k!RZkii~~~nV Do not attempt to heat any 3. 4. 5. 6. 7. Place 5-7 regular size tea bags, or 2-4 level tablespoons of loose tea in a tea ball, and place into the brewer. Do not place sugar in the brewer along with the tea It will clog the brew lever.
. When the tea is done steeping, a lever automatically opens to dispense tea into the pitcher filled with ice. The machine will then shut off automatically. See !figure 4. The indicator light will turn off to let you know the cy cle is over. Grasp the molded plug and unplug the power cord. CAUTION: Some residual steam may escape from the brewer when the cycle is over 9. CAUTION: Use care when lifting the brewer 1 FIGURE 4 from the pitcher. A seal may have formed dur ing the brewing process.
Deliming The Iced Tea PotTM must be delimed when you begin to notice an increase in heating time of the water in the brewer. This condition may be caused by a buildup of lime and mineral deposits from your water. The frequency of cleaning depends upon the hardness of the water used. The following table gives the suggested cleaning intervals.
Notes 31
Notes 31
Limited Warranty Mr. Coffee warrants to the purchaser that the Series TM5/TM10 by Mr. Coffee’ (except for cord set and pitcher) is free from manufacturer defects in material and workmanship for a period of one year from the date of. original purchase when used and compliance with directions as outlined the manufacturer’s instructions, which will constitute reasonable and necessary maintenance by the purchaser. In case of manufacturer defects in material or workmanship, Mr.
