Preface Notebook User’s Manual
Preface Contents Chapter 1: Preface Content ............................................................................ 1-2 Regulations and Statements ......................................... 1-4 FCC-B Radio Frequency Interference Statement ....... 1-4 FCC Conditions ........................................................... 1-4 CE Conformity ............................................................. 1-4 Battery Regulations ..................................................... 1-5 WEEE Statement ....
AC Power .................................................................... 3-3 Battery Power .............................................................. 3-3 Power Management in Windows OS .......................... 3-5 Energy Saving Tips ..................................................... 3-7 Basic Operations ............................................................ 3-8 Safety and Comfort Tips .............................................. 3-8 Knowing the Keyboard ................................
Preface Regulations and Statements FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Battery Regulations European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. Taiwan: For better environmental protection, waste batteries should be collected separately for recycling or special disposal.
Preface India RoHS This product complies with the "India E-waste (Management and Handling) Rule 2011" and prohibits use of lead, mercury, hexavalent chromium, polybrominated biphenyls or polybrominated diphenyl ethers in concentrations exceeding 0.1 weight % and 0.01 weight % for cadmium, except for the exemptions set in Schedule 2 of the Rule. Turkey EEE regulation Conforms to the EEE Regulations of the Republic Of Turkey.
Do not leave the equipment in an unconditioned environment with a storage temperature above 60OC (140OF) or below 0OC (32OF), which may damage the equipment. This unit should be operated under maximum ambient temperature of 35OC (95OF). Make sure the power voltage is within safety range and has been adjusted properly to the value of 100~240V before connecting the equipment to the power outlet. Always unplug the AC power cord before installing any add-on card or module to the equipment.
Preface If any of the following situations arises, get the equipment checked by a service personnel: The power cord or plug is damaged. Liquid has penetrated into the equipment. The equipment has been exposed to moisture. The equipment has not worked well or you can not get it work according to User’s Manual. The equipment was dropped and damaged. The equipment has obvious signs of breakage.
2 Introductions
Introductions Congratulations on becoming an user of this notebook, the finely designed notebook. This brand-new exquisite notebook will give you a delightful and professional experience in using notebook. We are proud to tell our users that this notebook is thoroughly tested and certified by our reputation for unsurpassed dependability and customer satisfaction. Manual Map This User’s Manual provides instructions and illustrations on how to operate this notebook.
Product Overview This section provides the description of basic aspects of the notebook. It will help you to know more about the appearance of this notebook before using it. Please be aware that the notebook shown in this section may vary from the actual one that users purchased. Top-open View The figure of top-open view and description shown below will lead you to browse the main operating area of your notebook. The figures shown here are for reference only.
Introductions 1. Webcam This built-in Webcam can be used for picture taking, video recording or conferencing, and any other interactive applications. Webcam LED indicator, next to the webcam, glows white when webcam function is activated; LED goes out when this function is turned off. 2. Internal Microphone This is the built-in microphone and its function is the same with microphone. 3. Soundbar Speakers Give high quality sound blaster with stereo system and Hi-Fi function supported. 4.
This notebook may be preinstalled with a gaming utility, Dragon Gaming Center, providing users an astonished and efficient solution in game playing. With Dragon Gaming Center preinstalled, use both Fn and F4 buttons to bring up the tag of [Instant Play: Play Key Setting] to define the quick launch button for launching a + particular application. Once the setting has been made, use Dragon Gaming Center or User Defined (optional) Fn and F4 buttons to launch the appointed application.
Introductions Press and hold the Fn key, and then press the F10 key repeatedly to turn Airplane mode on or off recurrently. For flight safety consideration, it is always recommended to turn Airplane Mode on when you are in flight. + Refer to the Airplane mode switch icon under [Start/ Settings/ Change PC Settings/ Network / Airplane Airplane mode mode] on the desktop to check the device status.
Front Side View 1. Status LED Battery Status Glowing white when the battery is being charged. Continuously blinking amber if the battery fails and it is recommended to replace a new battery. Consult the local dealer for purchasing an equivalent type of battery recommended by the manufacturer. Battery LED goes out when it is fully charged or when the AC/DC adapter is disconnected. Wireless LAN (WiFi) This LED indicator glows white when Wireless LAN (WiFi) function is enabled.
Introductions Note: Functions listed above may be optionally supported depending on the model users purchased. Warning: For flight safety consideration, make sure the WLAN and Bluetooth LED indicators go out when you are in flight. To enable or disable the WLAN or Bluetooth function in Windows 8.x operating system, please refer to the instructions provided in Wireless Activation in chapter 3. Contact the local distributor for further information about wireless connection if necessary.
Right Side View 1. Ventilator The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation. 2. Kensington Lock This notebook provides a Kensington Lock hole, which allows users to secure the notebook in place with a key or some mechanical PIN device and attached through a rubberized metal cable.
Introductions 6. Battery Reset Hole If your computer system hangs, you can use a straightened paperclip to insert this hole and reset the notebook. Note: After resetting the computer system, please connect the AC power when first bootup the notebook.
Left Side View 1. Ventilator The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation. 2. RJ-45 Connector The 10/100/1000 Ethernet connector is used to connect a LAN cable for network connection. 3. HDMI Connector HDMI (High Definition Multimedia Interface) is a new interface standard for PCs, displays and consumer electronics devices that supports standard, enhanced and high-definition video, plus multi-channel digital audio on a single cable. 4.
Introductions 7. Audio Port Connectors Make high quality sound blaster with stereo system and Hi-Fi function supported. Headphone out/ SPDIF-out Used for speakers or headphones. The S/PDIF connector is also provided for digital audio transmission to external speakers through an optical fiber cable. Connect the Front speakers here. Line In Used for an external audio device. Connect the Rear speakers here. Microphone 2-12 Used for an external microphone.
Bottom Side View 1. Ventilator The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation. 2. Woofer Speaker The woofer speaker is to reproduce low-pitched audio frequencies known as bass.
Introductions Specification The specification may change without notice. The actual products sold are different from areas. Please check the detailed specification with your local dealers. Physical Characteristic Dimension 418.5 (W) x 287 (D) x 21.8 (H) mm Weight 2.
RJ45 x1 HDMI x1 Mini-DisplayPort x2 Card Reader x 1 (SD4.0) The supported memory cards may vary without notice. Communication Port LAN 10/ 100/ 1000Mb Ethernet Wireless LAN Supported Bluetooth Supported Display LCD Type 17.3" full HD display Brightness Controlled by K/B hot-keys Video Graphics NVIDIA GeForce discrete graphics card+ Intel HD graphics card UMA With NVIDIA Optimus supported VRAM GDDR5 Depends on the model you purchased.
Introductions Others Compatibility WHQL Kensington Lock Hole x1 2-16
3 Getting Started
Getting Started Begin to Use the Notebook For a new user of this notebook, we would like to suggest you follow the illustrations below to begin to use the notebook.
Power Management AC Power It is strongly recommended to connect the AC/DC adapter to the notebook and use the AC power while using this notebook for the first time. When the AC power is connected, recharging the battery will start immediately. Note that the AC/DC adapter included in the package is approved for your notebook; using other adapter model may damage either the notebook or other devices attached to it. Do not cover the AC/DC adapter since it may generate a certain heat while in use.
Getting Started The battery pack uses Lithium-ion battery cells that have no “memory effect.” It is unnecessary to discharge the battery before recharging. However, to optimize the life of battery, we suggest that consuming the battery power completely once a month is necessary. 3-4 The actual charging time will be determined by the applications in use.
Power Management in Windows OS Power management of personal computers (PCs) and monitors has the potential to save significant amounts of electricity as well as deliver environmental benefits. To be energy efficient, turn off your display or set your PC to standby/hibernate mode after a period of user inactivity.
Getting Started Click on Power Options. Then select a power plan that meets your personal needs. The Power icon will present various and relative options as following: You can wake up your computer from power saving mode by pressing the power button.
Energy Saving Tips Activate the ECO power saving function to manage the computer’s energy consumption. Turn off the monitor after a period of user inactivity. Utilize the Fn and F12 sleep mode keys to turn into power saving mode. Tune the settings in Power Options under Windows OS to optimize the computer’s power management.
Getting Started Basic Operations If you are a beginner to the notebook, please read the following instructions to assure your own safety, and make yourself comfortable during the operations. Safety and Comfort Tips The notebook is a portable platform that allows you to work anywhere. However, choosing a good workspace is important if you have to work with your notebook for a long period of time.
1. Your work area should have enough illumination. 2. Choose the proper desk and chair and adjust their height to fit your posture when 3. When sitting on the chair, adjust the chair’s back (if available) to support your back 4. Place your feet flat and naturally on the floor, so that your knees and elbows have the 5. Put your hands on the desk naturally to support your wrists. 6. Adjust the angle/position of the LCD panel to have an optimal view. operating. comfortably.
Getting Started Knowing the Keyboard This notebook provides a full-functioned keyboard. This keyboard can be divided into four categories: Typewriter keys, Cursor keys, Numeric keys and Function keys. 3-10 1. Typewriter keys 2. Numeric keys 3.
Typewriter Keys In addition to providing the major function of the keyboard, these typewriter keys also provide several keys for special purposes, such as [Ctrl,] [Alt,] and [Esc] key. When the lock keys are pressed, the corresponding LEDs will light up to indicate their status: 1. Num Lock: Press this key to toggle the Num Lock on and off. When this function is activated, you can use the numeric keys that are embedded in the typewriter keys. 2.
Getting Started + + + + Decrease the LCD brightness. Increase the LCD brightness. Decrease the built-in speaker’s volume. Increase the built-in speaker’s volume. Disable the computer’s audio function. + Force the computer into sleep state (depending on the system + + configuration). Increase the keyboard LED brightness level. Decrease the keyboard LED brightness level. + Quick Launch [Fn] Keys Use the [Fn] keys on the keyboard to activate the specific applications or tools.
However, if Dragon Gaming Center is not installed or removed, use both Fn and F4 buttons to launch the User Defined application. + provided by ECO Engine, or to turn this function off ECO Engine recurrently. (Power Saving) + Press and hold the Fn key, and then press the F5 key repeatedly to switch among various power saving modes Press and hold the Fn key, and then press the F6 key to turn the Webcam function on. Webcam Press again to turn it off.
Getting Started Wireless Activation 1. Find the Settings icon on the desktop and click on it. 2. Enter the PC settings main page by clicking on Change PC settings. 3. Unfold the Airplane mode selections under Network. 4. Make sure Airplane mode is set to Off here. 5. Turn the Wi-Fi or Bluetooth function on/ off by sliding the function switch bar. Refer to the Status LED to check the device status. 1. When Airplane mode is set to ON, the Wi-Fi and Bluetooth function will be disabled at once. 2.
Knowing the Touchpad The touchpad integrated in your notebook is a pointing device that is compatible with standard mouse, allowing you to control the notebook by pointing the location of the cursor on the screen and making selection with its two buttons. 1. Cursor Movement Area This pressure-sensitive area of the touchpad, allows you to place your finger on and control the cursor on the screen by moving one of your finger. 2. Right / Left Buttons Acts as the mouse’s right/ left button.
Getting Started Point and Click When you have moved and placed the cursor over an icon, a menu item or a command that you want to execute, simply tap slightly on the touchpad or press the left button to select. This procedure, called as point and click is the basics of operating your notebook. Unlike the traditional pointing device such as the mouse, the whole touchpad can act as a left button, so that your each tap on the touchpad is equivalent to pressing the left button.
Knowing the Smart Pad The Smart Pad integrated in your notebook allows users to perform various actions with multi-finger taps and gestures while operating the notebook, and is capable to detect the changes of the multi-finger movement performed by users precisely. This significant Smart Pad will surely bring users not only an efficient but also an enjoyable experience of using the notebook. 1.
Getting Started About Hard Disk Drive Your notebook is equipped with a 2.5-inch hard disk or mSATA SSD (optional). The hard disk drive is a storage device with much higher speed and larger capacity than other storage devices, such as the floppy disk drive and optical storage device. Therefore, it is usually used to install the operating system and software applications. To avoid unexpected data loss in your system, please backup your crucial files regularly.
Connecting the External Devices The I/O (input/output) ports on the notebook allow you to connect peripheral devices and communication devices. All functions and devices listed here are for reference only.
Getting Started Communication Devices The functions listed here are supported optionally, depending on the model users purchased. Contact the local dealer for detailed information.
