Operation Manual SERIES MODEL WBH16 (GX390K1QA2 GASOLINE ENGINE RECOIL START) MODEL WBH16E (GX390K1QAE2 GASOLINE ENGINE ELECTRIC START) power buggy Revision #9 (12/03/10) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
Proposition 65 Warning Engine exhaust and some of its constituents, and some dust created by power sanding, sawing, grinding, drillingandotherconstructionactivities contains chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. Some examples of these chemicals are: Leadfromlead-basedpaints. Crystalline silicafrombricks. Cementandothermasonryproducts. Arsenicandchromiumfromchemically treatedlumber.
notes WBH16/WBH16E power buggy • operation and parts manual — rev.
Table of Contents WBH16/WBH16E Power Buggy Proposition 65 Warning............................................ 2 Table Of Contents..................................................... 4 Safety Information............................................... 5-10 Specifications.................................................... 11-12 Dimensions............................................................. 13 General Information................................................ 14 Components.........................
Safety Information Do not operate or service the equipment before reading the entire manual. Safety precautions should be followed at all times when operating this equipment. Failure to read and understand the safety messages and operating instructions could result in injury to yourself and others. Potential hazards associated with the operation of this equipment will be referenced with hazard symbols which may appear throughout this manual in conjunction with safety messages.
Safety Information general saFety Caution never operate this equipment without proper protective clothing, shatterproof glasses, respiratory protection, hearing protection, steel-toed boots and other protective devices required by the job or city and state regulations. Avoid wearing jewelry or loose fitting clothes that may snag on the controls or moving parts as this can cause serious injury. never operate this equipment when not feeling well due to fatigue, illness or when under medication.
Safety Information poWer Buggy saFety Caution danger Engine fuel exhaust gases contain poisonous carbon monoxide. This gas is colorless and odorless, and can cause death if inhaled. The engine of this equipment requires an adequate free flow of cooling air. never operate this equipment in any enclosed or narrow area where free flow of the air is restricted. If the air flow is restricted it will cause injury to people and property and serious damage to the equipment or engine.
Safety Information do not operate the power buggy at excessive speeds. Reckless operation may cause accidents and severe injury. Slow down when approaching people, wet areas, and going up and down grades. It is the responsibility of the operator to adjust speed, as necessary, depending on the conditions of the road or path. alloW extra time to stop when operating the power buggy ion wet surfaces or loosely graded materials.
Safety Information engine saFety Warning do not place hands or fingers inside engine compartment when engine is running. never operate the engine with heat shields or guards removed. Keep fingers, hands hair and clothing away from all moving parts to prevent injury. alWays shut down the engine before performing service or maintenance. do not remove the engine oil drain plug while the engine is hot.
Safety Information alWays recharge the battery in a well-ventilated environment to avoid the risk of a dangerous concentration of combustible gases. transporting saFety If the battery liquid (dilute sulfuric acid) comes into contact with clothing or skin, rinse skin or clothing immediately with plenty of water. alWays shutdown engine before transporting.
specifications Table 1. Specifications (Power Buggy) Models WBH16/WBH16E Wheelbase 44 in. (1,117.6 mm) Overall Length 103 in. (2,616.2 mm) Overall Width- Dual Wheels 43.25 in. (1,098.6 mm) Maximum Weight Capacity 30.25 in. (738.65 mm) 2,500 lbs. (Dual Wheels) (1,136 kg) Overall Width- Single Wheel 43.25 in. (1,098.6 mm) Maximum Weight Capacity 1,100 lbs. (499 kg) (Single Wheel) Overall Height 53 in. (1346.2 mm) Operating Weight 1,200 lbs. (544.2 kg.) Ship Weight Palletized 1,260 lbs. (585 kg.
specifications Table 2. Specifications (Engine) GX390K1QA2 (Recoil Start) Model GX390K1QAE2 (Electric Start) 3.46 x 2.51 in. Bore X Stroke (88 x 64 mm.) Displacement 389 cc Maximum Power 13.0 hp (3,600 rpm) Continuous Output 9.0 hp (3,600 rpm) Maximum Torque 19.5 ft-lbs. (2.7 kg-m) @ 2,500 rpm Compression Ratio 8.0 : 1 Idle Speed 1,400 ± rpm Maximum No Load RPM 3.850 ± rpm 1 gal./hr. Specific Fuel Consumption (3.78 liters/hr.) Fuel Tank Capacity 5.5 gal. (20.81 liters) Crankcase Oil Capacity 1.16 qts. (1.
dimensions Side View rear View Figure 1. WBH16/WBH16E Dimensions WBH16/WBH16E power buggy • operation and parts manual — rev.
general information The MQ Whiteman Power Buggy, Models WBH16 (recoil start) and WBH16E (electric start) are intended for the transportation of concrete, concrete spreading and spot pouring. In addition, the WBH16/WBH16E is designed for landscaping applications, material sub-base distribution, job site cleanup and material transport. The Power Buggy is equipped with a 6-inch dump height which provides clearance and enables the operator to maneuver over any form height.
components Figure 2. WBH16/WBH16E Power Buggy Components 1. Tub or Bucket — Used for the transportation of material. Tub holds approximately 16 cubic feet (0.59 cubic yards) of water. 10. Engine — The WBH16 uses a HONDA GX390K1QA2 (recoil start) engine. The WBH16E uses a HONDA GX390K1QAE2 (electric start) engine. 2. Handle Bar (Steering) — This handle bar is used to steer the buggy. When driving the buggy, use both hands and hold onto both handle bar grips. 11.
basic engine Figure 3. Honda GX390K1 Engine 1. Fuel Filler Cap — Remove this cap to add unleaded gasoline to the fuel tank. Make sure cap is tightened securely. DO NOT over fill. 8. Spark Plugs — Provides spark to the ignition system. Set spark plug gap to 0.70- 0.76 mm (0.028 - 0.030 in.) Clean spark plug once a week. 2. Throttle Lever — Used to adjust engine RPM speed (lever advanced forward - SLOW, lever back toward operator - FAST). 9. Muffler — Used to reduce noise and emissions. 3.
inspection Before Starting 1. Read safety information at the beginning of manual. 2. Clean the machine, removing dirt and dust, particularly the engine cooling air inlet, carburetor and air cleaner. 3. Check the air filter for dirt and dust. If air filter is dirty, replace air filter with a new one. 4. Check carburetor for external dirt and dust. Clean with dry compressed air. 5. Check fastening nuts and bolts for tightness. Engine Oil Check 1.
inspection Parking Brake Check Check the brakes as outlined in the maintenance section of this manual. Linkage Check Check and make sure that all linkages within the buggy are functioning correctly. Steering Check 1. Check and make sure that the power buggy's steering turns freely and that there is no binding. 2. Make sure that the zerk fitting for the steering has been lubricated. Dump Cylinder Check 1. Check the power buggy's dump cylinder as outlined in the operation section of this manual. 2.
OPERATION CAUTION DO NOT attempt to operate the power buggy until the Safety Information, General Information, and Inspection sections of this manual have been read and thoroughly understood. 4. Place the choke lever (Figure 10) in the OPEN position if starting a warm engine or the temperature is warm. ELECTRIC START (WBH16E only) 1. Before attempting to start the power buggy, make sure that the safety kill switch (Figure 19) is not pushed in. The power buggy will not start with the kill switch engaged.
OPERATION 7. Make sure the choke lever is in the OPEN position (Figure 10) before operating the power buggy. Before the buggy is placed into operation, run the engine for several minutes. Check for fuel leaks, and noises that would associate with a loose guard or cover. 4. If the engine has started, slowly push the choke lever inward to the RUN position. If the engine has not started, repeat steps 1 through 3. RECOIL START 1.
OPERATION Parking Brake/Direction Lever Before the power buggy can be put into operational use, it is best to perform a test run to make certain that all components are functioning properly. 3. When using the buggy for the first time, test the brake. With the right foot, step up and place it on the brake pedal (Figure 18). Gradually apply pressure to the brake pedal until the buggy comes to rest. 1. Place the buggy on flat solid ground. 2. Engage the parking brake lever. 3.
OPERATION EMERGENCY SHUTDOWN CAUTION The WBH16/WBH16E is equipped with a safety kill switch. This switch is located on the right side of the handle bar. 1. Press the power buggy's kill switch (Figure 19) and listen for the engine to stop. DO NOT steer the buggy left or right when traveling up or down on a grade. Travel in a straight path. CAUTION Avoid sudden and quick turns. When steering, turn the handle bar slowly. Always face the controls when traveling. TRAVELING ON A SLOPE 1.
OPERATION 2. When going up or down a slope, always travel in the forward direction (Figure 22). NOTICE Releasing either one (dump control lever or pedal) before dump is completed, will cause the tub to return to the horizontal position. Figure 22. Slope Travel Direction Tub (Bucket) Dumping The hydraulic dump can be controlled by hand (dump control lever) or foot (dump pedal). 1. To activate the hydraulic dump, press down on the dump pedal (Figure 23) or move the dump control lever forward.
maintenance Engine Refer to the Honda engine owner’s manual for specific information. 1. Check engine oil after every 10 hours of operation and maintain proper levels. 2. Drain oil after every 50 hours of operation and refill with grade of oil recommended below: Above 40 °F. (13 °C.) - S.A.E. 30 Below 40 °F. (13 °C.) - S.A.E. 20 5. Replace hydraulic oil after every 200 hours of operation. The hydraulic oil filter should be changed each time the hydraulic oil is changed.
maintenance pump control lever adjustment Table 4. Tire Wear Troubleshooting If the power buggy tends to creep in the forward or reverse direction after you release the speed control lever, the pump control lever requires adjustment. 3. Place the machines drive wheels on jacks or blocks free from ground contact. 4. Locate the pump control lever adjusting bolt. 5. Loosen the jam nut. 6.
troubleshooting troubleshooting (power Buggy) symptom Possible Problem solution Speed control cable out of adjustment? Adjust speed control cable. Replace cable if necessary Hydraulic oil level low.? Check hydraulic oil level. Add oil if necessary. Contaminated hydraulic oil filter? Replace hydraulic oil filter. Low engine RPM? Check engine speed. Forward/Reverse lever in neutral position? Place lever in either forward or reverse position. Check hydraulic motors.
troubleshooting troubleshooting (engine) symptom Possible Problem solution Spark plug bridging? Check gap, insulation or replace spark plug. Carbon deposit on spark plug? Clean or replace spark plug. Short circuit due to deficient spark plug insulation? Check spark plug insulation, replace if worn. Improper spark plug gap? Set to proper gap. Fuel reaching carburetor? Check fuel line. Water in fuel tank? Flush or replace fuel tank. Fuel filter clogged? Replace fuel filter.
troubleshooting troubleshooting (engine) - continued symptom Weak in power, compression is proper and does not misfire. Weak in power, compression is proper but misfires. Engine overheats. Rotational speed fluctuates. Recoil starter malfunctions. (if applicable) Starter malfunctions. Possible Problem Air cleaner dirty? Clean or replace air cleaner. Improper level in carburetor? Check float adjustment, rebuild carburetor. Defective spark plug? Clean or replace spark plug.
hydraulic system diagram WBH16/WBH16E power buggy • operation and parts manual — rev.
Operation Manual HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING UNITED STATES Multiquip Corporate Office 18910 Wilmington Ave. Carson, CA 90746 Contact: mq@multiquip.com MQ Parts Department Tel.
