User Manual


MountingSuggestions
Harley‐Davidson®2006‐201ϯWideTireSoftail
(Will
notfitonSoftailFat
boy)
2006‐201ϯSoftailCrossbones
2006
‐201ϯSoftailCust
om
2006‐201ϯSoftailNightTr
ĂiŶ
CycloneSoloSeatandFrameMountingPlate
InstallationHardwareIncluded:
(1)nosebracket#B30126 (2)blackrubberwashers
(1)¼‐20x1½”longhexheadbolt (1)blackplasticwasher
(1)¼‐20x½”longPhillipstrussheadscrew (5)¼flatwashers
(1)¾”thickplasticspacer (2)¼‐20x1½”longPhillipstrussheadscrews
(2)¼‐20flangenuts (1)¼‐20threadedstud
(2)¼‐20x¾”longPhillipstrussheadscrew (1)chromewasher
(2)rubberbumpers (1)¼‐20chromeacornnut
AttachMustangCycloneSoloseattoFrameMountingPlate
1.Attachnosebracket#B30126tobottomofframemountingplate.Insertthe¼‐20x½”longPhil‐
lipstrussheadscrewfromthetopside,throughthenosebracket,andsecurewiththe¼‐20flange
nut.
2.Alignthreethreade
dinsertsinbottomofsoloseatwith
threeholesinframemountingplate.
3.Atnoseend,insertthe¼‐20x1½”longhexheadboltwithwasherupthroughthenosebracket
andframemountingplate,throughthe¾”thickplasticspacerandintothreadedinsertinnoseof
seat.
4.Atbackendofseat,insertth
etwo¼‐20x¾”long
Phillipstrussheadscrewswithwashersup
throughtheframemountingplate,throughthetwoflatblackrubberwashersandintothetwo
threadedinsertsinthebottomoftheseat.Tightenallthreefasteners.
5.Ifthesoloseat
willbeusedintherearmost mountingposition,two5/16holesmustbedrilled
throughtheframemountingplateattheindicatedpoints.Thetworearfastenerswillbethe¼‐20x
1½”longPhillipstrussheadscrewswithwashersandthetwo5/8”thi
ckrubberbumpers.
