Specification

8/5/16
Acrylic
N/A
1.89 in x 30 yd (48 mm x 27.4 m)
!
!
!
!
!
!
! Conformable for hard-to-seal areas
!
181B-FX printed for easy inspector identification
!
25 Forge Parkway Franklin, MA 02038
1-800-343-7875 Fax [phone]
www.nashuatape.com
Applications
WATER HEATER INSTALLATION
Backing:
Printed Biaxially-Oriented Polypropylene Film
Adhesive:
Liner:
Specifications:
UL 181B-FX Listed
Colors:
Metallic
Available Size:
Acrylic Adhesive
Aggressive, high tack bond to insulation jacket
Low-odor adhesive
Mold and moisture-resistant
Conforms and bonds securely to water heater
insulation jacketing to seal seams and repair rips
and tears
Features
Benefits
Total Thickness
3.1 mils
79 μm
ASTM D-1000
Biaxially-Oriented Polypropylene Film
Tough and durable
Hand tearable for simple, quick installation
Low VOC Content
Can contribute toward satisfying EQ Credit 4.1
(Low Emitting Materials) under LEED®
Typical Test Values
Standard UOM
Metric UOM
Test Method
Adhesion to Steel
45 oz/in
4.92 N/cm
PSTC-101
Tensile Strength
34 lb/in
59.54 N/cm
ASTM D-1000
Recommended Storage Conditions: 32 - 90 °F at 50% RH ± 2%
Standard Shelf Life (at 25 °C): 24 months from date of manufacture
The information presented herein was prepared at BERRY PLASTICS CORPORATION (25 Forge Parkway Franklin, MA 02038) by qualified technical personnel. To Berry Plastics' knowledge it is true
and accurate. However, the information and recommendations are furnished for these products with the understanding that the purchaser or user, as the case may be, will independently determine that
the product is suitable for the intended use, and that such use complies with all applicable federal, state and local laws and regulations. The data are typical values submitted only for the user's
information and consideration, and do not constitute a warranty of any kind (including but not limited to a warranty of merchantability or of fitness for a particular purpose), or a representation for which
BERRY PLASTICS assumes any legal responsibility.
Operating Temperature
-10 to 250 °F
-17 to 121 °C
VOC Content
< 1 g/L
