The Attribute Editor (here showing the TYPES page).
The Attribute Editor affects the files selected in the Result list of the LIBRARY pane (see sec-
tion ↑3.2.7, Using the Result List) or the files within the folders selected for import in the
FILES pane (see section ↑3.5.5, Using the Result List).
The Attribute Editor is organized into various pages:
▪ In the LIBRARY pane of the Browser, all pages are available: BANK, TYPES, MODES (In-
strument/Effect presets only), and PROPERTIES.
▪ In the FILES pane of the Browser, only the TYPES and MODES pages are available.
►
Click the desired tab at the top right of the Attribute Editor to show the corresponding
page.
You can adjust the overall height of the Attribute Editor by dragging its upper border.
The number of items selected appears in yellow in the upper left corner of the Attribute Editor.
Displaying Attributes of Factory Files
When browsing in the LIBRARY pane, if the files selected in the Result list are factory files
(i.e. files from any factory content) this will be indicated by a yellow read only item label next
to the EDIT button at the bottom of the Browser:
Browser
Editing the Files’ Tags and Properties
MASCHINE STUDIO - Manual - 113
