4.3.5 Saving Groups
You can save your Groups as individual files (extension “.mxgrp”). This can be only done in the
software.
Saving Your Modifications into the Original Group File
If you have made changes to a Group loaded in your Project, you can save your modifications
as follows:
►
Right-click (on Mac OS X: [Ctrl]-click) the Group in the Group List or the Group name in
the top left corner of the Pattern Editor and select Save from the context menu:
→
Your modifications are saved to the Sound file.
Even if you don’t save a Group individually, its current settings will still be saved with your
Project. But once a Group is saved and tagged, it is available in the Browser for use in oth-
er Projects.
You cannot save changes to factory files — these files are read-only. If you run the Save com-
mand on a factory file, it automatically turns into the Save As… command: a Save Group dia-
log opens and lets you save your modified Group to your user library. See next paragraph for
more details. The same happens with Groups you have built from scratch.
Managing Sounds, Groups, and Your Project
Managing Groups
MASCHINE STUDIO - Manual - 160
