2. In the Choke section click the Group value and select the desired group 1–8 from the list
or choose None (default setting) to remove the Sound from its current Choke group.
3. In the same Choke section click the Mode value (Master or Slave) to switch the Sound
between Master (default setting) and Slave mode.
4. Repeat the steps above to assign other pads to the same Choke group.
The Hi-hat is an ideal candidate for making use of Choke groups! See ↑10.4.3, Hi-hat –
Memory for more details!
5.1.4.1 Using Choke Groups on Your Controller
To assign the selected pad(s) / Sound slot(s) to a Choke group and set its/their Choke mode on
your controller:
1. Hold the PAD MODE button to enter Pad Mode (or press PAD MODE + Button 1 to pin it).
2. If necessary, press the Page Left button to switch to the first Parameter page of the Pad
Mode.
3. Turn Knob 1 (CHOKE GROUP) to select the desired Choke group 1–8 for that pad or choose
NONE (default setting) to remove the pad from its current Choke group.
4. Turn Knob 2 (CHOKE MODE) to select the Choke mode from MASTER (default setting) or SLAVE
for that pad.
5. Release PAD MODE (or press it again if you pinned the mode).
5.1.5 Using Link Groups
When your pads are in Group mode, Link groups allow you to link pads with each other: this
can be used to trigger multiple Sounds when pressing only one pad. Each pad of a Group can
be assigned to one of eight Link groups. A pad may be set as a Master or Slave in the Link
group:
▪ If the pad is set to Master (default setting) it will trigger other pads in the same Link
group.
▪ If the pad is set to Slave it will only trigger its own Sound, even if it is part of a Link group
— but be triggered by pads set to Master within the same group.
You may set more than one pad as Master or Slave within the same group.
Playing on Your Controller
Adjusting Your Pads
MASCHINE STUDIO - Manual - 186
