Since soloing a Sound mutes all Sounds except one, the MUTE button can then be used to
“release” Sounds that have been muted. You can use this technique to create a break-
down: Solo a given Sound such as a kick drum, then build the track up again by bringing
the muted Sounds back in one at a time while holding the MUTE button.
5.2.2.2 Solo Shortcut on the MASCHINE STUDIO Controller
Your MASCHINE STUDIO controller provides an additional shortcut for the Solo function di-
rectly available in Control mode:
►
In Control mode, press Button 4 (SOLO) to solo the focused Sound or Group.
Pressing Button 4 (SOLO) again will unsolo the Sound/Group.
This shortcut can be useful to quickly isolate the audio of the channel you are currently
working on without switching to another mode on your controller.
5.2.3 Choke All Notes
The Choke All Notes feature allows you to kill any note or event currently playing in your
Project. This affects the audio coming from all Plug-ins (Internal, Native Instruments, and Ex-
ternal).
Choke All Notes is only available on your controller:
►
Press SHIFT + MUTE to choke all playing notes.
Choke All Notes can be useful in various situations:
▪ as a creative tool in a live performance, e.g. to create stutter beaks,
▪ as a workflow aid, to stop long one-shot Samples that still continue playing after you have
stopped the sequencer,
▪ as a first panic button, if you are not sure where in your Project a particular sound is com-
ing from, and you want to get rid of it.
Contrary to the Mute function, Choke All Notes is not turning any Group/Sound into another
state. Instead, all audio voices currently playing are instantaneously killed. The killed voi-
ces cannot be reactivated and are freed up for subsequent notes according to the polypho-
ny setting. Voices triggered by subsequent notes will play normally.
