![](/manual/native-instruments/22550/user-manual-english/images/img-242.png)
3. Select the desired preset in this submenu.
→
The preset is loaded into the Plug-in.
Each VST/AU instrument or effect might handle its presets (or patches, programs…) different-
ly. Please refer to the plug-in documentation to find out how to reveal its presets (or a particu-
lar set of presets) to the host.
For example, in MASSIVE, ABSYNTH 5, and FM8, you need to enable the Program List
and fill it up with the desired patches in order to expose these and see them appear in the
Presets submenu of the Plug-in menus in MASCHINE.
Some VST/AU plug-ins can run both as instrument and effect plug-ins. When loading a pre-
set for such a plug-in, check that the preset can be effectively loaded in the current Plug-in
slot — in particular, take care to load presets for instruments in the first Plug-in slot of
Sounds only! To avoid any mistake, one solution is to name your VST/AU presets explicitly
(e.g., by adding a suffix “[FX]” to the effect presets).
MASCHINE allows you also to change the preset in your Native Instruments or third-party VST/
AU plug-in via MIDI Program Change messages. For more information, see section ↑8.2.2,
Controlling Parameters via MIDI and Host Automation.
Saving VST/AU Presets as MASCHINE Plug-in Presets
Once you have loaded a VST/AU preset (user preset of a Native Instruments instrument/effect
or any preset of a third-party VST/AU instrument or effect) using the method described above,
you can save it as a Plug-in preset in MASCHINE via the Save As… or Save As Default… com-
mands of the Plug-in menu (see section ↑6.1.9, Saving and Recalling Plug-in Presets). Once
this is done, your preset will be available as a user preset in the Instrument or Effect category
of the MASCHINE Browser.
6.3.5 Multiple-Output Plug-ins and Multitimbral Plug-ins
MASCHINE allows an extended use of multiple-output Plug-ins as well as multitimbral Plug-
ins.
Multiple-Output Plug-ins
Multiple-output Plug-ins are Plug-ins with more than one audio stereo output.
Working with Plug-ins
Using Native Instruments and External Plug-ins
MASCHINE STUDIO - Manual - 242
