7.1.3.1 Following the Playback Position on the MASCHINE STUDIO Controller
To follow the playhead position in the Event area during playback:
1. Press ARRANGE to enter Arrange mode.
2. Press Button 3 (FOLLOW).
→
Both Button 3 and the FOLLOW label underneath light up. In the software the Event area
will now switch to the next Pattern portion (with the same zoom factor) as soon as the
playhead reaches the end of the portion currently displayed. This way, you always see the
Pattern portion that is currently played. You can press ARRANGE again to leave Arrange
mode and switch to another mode: the Follow function will stay active.
The Event area will stop following the playhead as soon as you manually scroll to another
portion of the Pattern.
The Follow function simultaneously affects various displays in the software and on your con-
troller:
▪ In the software the Follow function affects both the Pattern Editor and the Arranger.
▪ On your controller the Follow function affects the displays in Arrange mode (for both SCENE
and PATTERN pages), Events mode, Step mode, and Note Repeat mode. Additionally, in
Step mode the Follow function affects the pads: With Follow enabled, when the playhead
has gone across all 16 steps shown by the pads on your controller, the pads switch to the
next 16 steps of the Pattern, if any. See section ↑7.3, Recording Patterns with the Step
Sequencer for more information on Step mode.
If the playback position is outside any Clip referencing the Pattern currently displayed, the
Event area will not follow the playhead, even if the Follow function is active. As soon as the
playhead enters any Clip referencing the selected Pattern, the Event area will follow the
playhead.
7.1.4 Jumping to Another Playback Position in the Pattern
You can use the timeline above the Event area to set the playback to the desired position. For
example, this can be useful to check a particular transition between events in your Pattern
without waiting for the whole Loop Range to be looped.
