The focused Sound slot is highlighted.
If the desired Sound does not appear in the Sound List, use the scroll bar at the right end
of the Pattern Editor or turn your mouse wheel while hovering the Pattern Editor to display
any hidden Sounds.
You can also select multiple Sounds at once to apply changes to all of them. See section
↑4.1.3, Selecting Multiple Sounds or Groups for more information.
2.3.1.1 Setting the Focus on a Group or a Sound on the MASCHINE STUDIO Controller
Setting the Focus on a Group
1. If necessary, press SHIFT + the desired Group button A–H to switch to the Group bank
containing the desired Group.
2. Press the desired Group button A–H.
→
The corresponding Group is now in focus.
Once the Group is focused you can use Button 1–3 above the left display to quickly switch
between the Master, the focused Group and the last focused Sound in that Group! See sec-
tion ↑2.3.2, Switching Between the Master, Group, and Sound Level for more information.
Setting the Focus on a Sound
1. If you want to set the focus on a Sound located in another Group, first set the focus on its
Group as described above.
2. Press SELECT + the pad of the desired Sound (or simply press its pad if pads are in
Group mode).
