You can also close any floating window via the common button provided by your operating
system at the top left or right corner of the window. The Plug-in will be inserted back into
the Plug-in Strip.
9.5 Controlling Your Mix from Your Controller
Your MASCHINE STUDIO controller provides a dedicated Mix mode. The Mix mode provides an
overview of your channels via a mixing desk layout, similarly to the Mixer in the software’s Mix
view (see section ↑9.2, The Mixer).
The Mix mode on your controller and the Mix view in the software are independent from
each other: Switching views in the software does not switch the mode on your controller,
and inversely — for example, you can use your controller in Mix mode while displaying the
Arrange view in the software.
►
Press MIX to enter or leave Mix mode on your controller.
When Mix mode is active, the MIX button is lit.
In Mix mode the displays show channel strips for your Sounds and Groups:
The Mix mode on your controller.
9.5.1 Navigating Your Channels in Mix Mode
Like the Mixer in the software, the Mix mode lets you choose between displaying channel strips
at the Group level (i.e. all your Groups) or at the Sound level (i.e. all Sound slots of the focused
Group).
Controlling Your Mix
Controlling Your Mix from Your Controller
MASCHINE STUDIO - Manual - 431
