The parameters described below are presented as they appear in the Control area (Arrange

view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix

view). See ↑9.4, The Plug-in Strip for more information on this.

Main Page

Element Description

MAIN Section

Engine Selects the engine used in the Kick Plug-in. If you change this setting, please

refer to ↑10.2, The Kicks.

Tune Adjusts the pitch of the drum played by the middle C, measured in MIDI note

numbers and cents. Available values range from 38.00 to 62.00. The default

value is 50.00. For more details see ↑10.1.5, Pitch Range, Tuning, and MIDI

Notes.

Decay Adjusts the duration of the sound’s tail, measured as a percentage. Available

values range from 0.0 to 100.0 % (default: 50.0 %).

Punch Simultaneously adjusts the amount of the pitch envelope and the amount of

noise of the attack. Available values range from 0.0 to 100.0 % (default).

Impact Adjusts how hard the drum is hit. Available values range from 0.0 % (softest)

to 100.0 % (hardest). The default value is 75.0 %.

CRISPNESS Section

Mode Selects from two different crispness modes: Select A (default) for a tambour-

ine-like sound, and select B for a snare-like sound.

Decay Adjusts the duration of the crispness effect, measured as a percentage. Availa-

ble values range from 0.0 to 100.0 % (default: 34.0 %).

Amount Adjusts the amount of crispness, measured as a percentage. Available values

range from 0.0 to 100.0 % (default: 50.0 %).

Advanced Page

For this engine the Advanced page does not contain any parameters.

Using the Drumsynths

The Kicks

MASCHINE STUDIO - Manual - 449
