The commands in the Edit menu additionally shows which action will be undone/redone!
Take Undo is available in following situations:
▪ Recording in Control mode
▪ Recording in Step mode
▪ Recording modulation
Outside of these three situations, Take Undo has the same effect as Step Undo (see
above).
2.3.4.1 Undo/Redo on the MASCHINE STUDIO Controller
Both Step Undo and Take Undo are also available on your controller:
►
On your controller, perform the Take Undo operation by pressing UNDO. To perform the
Take Redo operation, press REDO.
►
On your controller, perform the Step Undo operation by pressing SHIFT + UNDO. To per-
form the Step Redo operation, press SHIFT + REDO.
2.3.5 Pinning a Mode on Your Controller
Besides the default Control mode, your controller has various other modes of operation, which
you can enter by pressing their dedicated buttons. Depending on their purpose and workflow,
these controller modes are of two types:
▪ Temporary modes only stay active as long as you hold down their button on the controller.
When you release the button, your controller returns to Control mode. This is for example
the case with the MUTE button.
▪ Permanent modes stay active even if you release their button. To deactivate them, you
must press their button a second time. This is for example the case with the BROWSE
button.
